The Bray Series 70 Industrial Electric Actuator is a robust solution designed for various quarter turn applications, including butterfly valves and ball valves. With torque outputs ranging from 600 to 18,000 lb.in. (68 to 2033 Nm), it offers direct mounting compatibility with Bray and other standard butterfly valves, eliminating the need for additional components. Featuring a manual declutchable override handwheel for user convenience, this actuator is available in On/Off and modulating models compatible with 24, 110, and 220 VAC power sources. Enclosed in a NEMA 4X and IP65 rated housing with an industrial polyester finish, the Series 70 is ideal for outdoor applications like cooling tower valves. The advanced Servo Pro modulating control card ensures seamless integration with analog control signals prevalent in building automation systems.
Product Specifications
Specifications Agency Listings 120v
UL, CE, CSA
Specifications Ambient Temperature
-20 to 150 ºF | -29 to 65 ºC
Specifications Aux Switches Two Spdt
10A (1/2 HP) at 220 VAC | 10A (1/3 HP) at 120 VAC
Specifications Conduit Entries 2
70-0061, 1/2" NPT | All Other Models, 3/4" NPT
Specifications Features
24 VAC | Aux. Switches | Heater | Modulating
Specifications Full Load Current Draw
1.8 A
Specifications Heater Optional
5 Watt, PTC style, self regulating
Specifications Housing
Die Cast Aluminum, Polyester Finish | NEMA 4X, IP 65
Specifications Motor Duty Cycle
Continuous Duty
Specifications Note
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the nearest Bray office. Bray controls shall not be liable for damages resulting from misapplication or misuse of its products.
Specifications Servo Modulating Models
Control Input - 0 to 10 VDC, 2 to 10 VDC, 0 to 5 VDC, 4 to 20 mA | Input Impedance - Voltage: 1000K Ohms; Current: 250 Ohms
Specifications Stroke Time
45 sec
Specifications Terminal Strip
14 to 24 AWG
Specifications Torque Output
600 in·lbs
Specifications Voltage
24 VAC
