Bray Series 70 Industrial Electric Actuator
Bray Series 70 Industrial Electric Actuator
SKU:ACT-dc2f21
The Bray Series 70 Actuator: Compact, reliable, and compliant with UL, CSA, and CE standards for easy industrial automation.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
Bray Series 70 Industrial Electric Actuator
$799.99
Quantity: 1
Claim Your Seller Account
Bray Series 70 Industrial Electric Actuator
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Bray Series 70 Industrial Electric Actuator is a robust solution designed for quarter turn applications like butterfly valves and dampers. With torque outputs ranging from 600 to 18,000 lb.in., this actuator mounts directly to industry standard valves, eliminating the need for brackets. Featuring a manual declutchable override handwheel, NEMA 4X and IP65 enclosure ratings, and compatibility with various analog control signals, the Series 70 ensures easy installation, flexibility, and reliability. It meets UL, CSA, and CE standards, offering a compact design, high visibility position indicator, and on-board diagnostics.
Product Specifications
Specifications Agency Listings 120v
UL, CE, CSA
Specifications Ambient Temperature
-20 to 150 ºF | -29 to 65 ºC
Specifications Aux Switches Two Spdt
10A (1/2 HP) at 220 VAC | 10A (1/3 HP) at 120 VAC
Specifications Conduit Entries 2
70-0061, 1/2" NPT | All Other Models, 3/4" NPT
Specifications Features
120 VAC | Aux. Switches | On/Off
Specifications Full Load Current Draw
1.0 A
Specifications Heater Optional
5 Watt, PTC style, self regulating
Specifications Housing
Die Cast Aluminum, Polyester Finish | NEMA 4X, IP 65
Specifications Locked Rotor Current Draw
2.1 A
Specifications Motor Duty Cycle
Continuous Duty
Specifications Note
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the nearest Bray office. Bray controls shall not be liable for damages resulting from misapplication or misuse of its products.
Specifications Servo Modulating Models
Control Input - 0 to 10 VDC, 2 to 10 VDC, 0 to 5 VDC, 4 to 20 mA | Input Impedance - Voltage: 1000K Ohms; Current: 250 Ohms
Specifications Stroke Time
30 sec
Specifications Terminal Strip
12 to 22 AWG
Specifications Torque Output
2000 in·lbs
Specifications Voltage
120 VAC
