Bronze Air, Gas, Water Valve Reducer 125 Size

Name: Bronze Air, Gas, Water Valve Reducer 125 Size
Brand: World Wide Metric, Inc.
SKU: VAL-1c7bb7
Price: 499.99 USD
Availability: OutOfStock

SKU:VAL-1c7bb7

Premium Bronze Reducing Valve for precise air, gas, or water flow control. DIN standards compliant.

$499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Bronze Reducing Valve is a reliable choice for regulating air, gas, or water flow. Crafted with high-quality Bronze body and Brass stem, it ensures durability and efficient performance. The synthetic Disc & Seat materials provide a tight seal, while the Reducer Pressure range of 1.5 - 6 bar allows precise control. This valve adheres to DIN 17052 and DIN 176724 standards, making it suitable for industrial applications requiring precision and durability.

Product Specifications

Specifications Actuators

Spring

Specifications Body Material

Bronze

Specifications C

210 mm

Specifications D

250 mm

Specifications Disc Material

Synthetic Material

Specifications H

580 mm

Specifications Hole Diameter

18 mm

Specifications L

400 mm

Specifications Max Inlet Pressure

16 bar

Specifications Number Of Holes

Specifications Reducer Pressure

1.5 - 6 bar

Specifications Seat Material

Synthetic Material

Specifications Size

125

Specifications Stem Material

Brass

Specifications Weight

226.5 kg

Bronze Air, Gas, Water Valve Reducer 125 Size
