Bronze DIN Specialty Valve with Reducer for Air, Gas or Water

Name: Bronze DIN Specialty Valve with Reducer for Air, Gas or Water
Brand: World Wide Metric, Inc.
SKU: VAL-03657e
Price: 499.99 USD
Availability: OutOfStock

SKU:VAL-03657e

Premium Bronze valve for air, gas or water control. DIN compliant, durable design for industrial applications.

$499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Bronze DIN Specialty Valve with Reducer is a high-quality valve designed for precise control in air, gas, or water systems. Crafted with a Bronze body and Synthetic Material disc and seat, it ensures durability and reliable performance. The Brass stem and Spring actuators provide smooth operation, while meeting strict DIN 17052 and DIN 176724 standards. With a reduction pressure range of 1.5 - 6 bar and a maximum inlet pressure of 16 bar, this valve offers optimal efficiency in industrial applications.

Product Specifications

Specifications Actuators

Spring

Specifications Body Material

Bronze

Specifications C

240 mm

Specifications D

285 mm

Specifications Disc Material

Synthetic Material

Specifications H

660 mm

Specifications Hole Diameter

22 mm

Specifications L

480 mm

Specifications Max Inlet Pressure

16 bar

Specifications Number Of Holes

Specifications Reducer Pressure

1.5 - 6 bar

Specifications Seat Material

Synthetic Material

Specifications Size

150

Specifications Stem Material

Brass

Specifications Weight

330.0 kg
