Brown & Sharpe Precision Gear Pumps

Name: Brown & Sharpe Precision Gear Pumps
Brand: AB Industrial
SKU: POS-f46721
Price: 599.99 USD
Availability: OutOfStock

SKU:POS-f46721

Reliable and precise gear pumps designed for high-pressure applications. Versatile with multiple configuration options.

$599.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Brown & Sharpe Precision Gear Pumps are engineered for exceptional reliability and precision performance. Constructed with materials like Cast Iron and hardened steel, these pumps are ideal for a wide range of applications. With options for internal bypass relief valves, various port configurations, and a selection of motors including AC, DC, and hydraulic, these pumps offer versatility and efficiency. The gear pumps are designed to handle pressures up to 2000 psi with flow rates of up to 1.5 gpm, meeting the stringent requirements of industrial and institutional settings.

Product Specifications

Specifications Coupling

Flex

Specifications Driver

AC Motor | Air Motor | DC Motor | Hydraulic Motor

Specifications Gal Rev

0.001

Specifications Gpm Max

1.5 gpm

Specifications Housing Material

Cast Iron

Specifications Hp

1 | 1/2 | 1/3 | 1-1/2 | 2 | 3 | 3/4

Specifications Hz

50 | 60 | DC

Specifications Manufacturer

Brown & Sharpe

Specifications Max Pressure Psi

2000 psi

Specifications Motor Enclosure

Explosion Proof | Hostile Duty | Stainless Steel | TEFC | Washdown

Specifications Phase

1 | 3

Specifications Port

3/8 in

Specifications Port Config

Inline

Specifications Port Type

FNPT

Specifications Relief Valve

WRV

Specifications Rotation

CCW | CW

Specifications Rpm Max

1725

Specifications Seal Material

Buna | FEP | Viton

Specifications Voltage

110 | 12 | 180 | 190 | 200 | 230 | 24 | 380 | 460 | 575 | 90

Brown & Sharpe Precision Gear Pumps
