Burndy/Souriau Type Relay Insulation Insert

Name: Burndy/Souriau Type Relay Insulation Insert
Brand: JC CHERRY INC.
SKU: HER-57695a
Price: 49.99 USD
Availability: OutOfStock

SKU:HER-57695a

High-performance Relay Insulation Insert for vacuum side use, available in various pole options and premium material choices like PEEK, PTFE, and Alumina.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Burndy/Souriau Type Relay Insulation Insert with Socket Pins and Wires is expertly crafted for vacuum side applications, ensuring optimal performance. Choose from high-quality materials like PEEK, PTFE, or Alumina, each offering exceptional heat resistance. Available in MS and Burndy/Souriau types, with options ranging from 4 to 48 poles, this product guarantees reliability and durability in demanding environments.

Product Specifications

Reasons Why Our Vacuum Connectors Are Chosen

The challenging development of vacuum componentsAs a connector manufacturer, we specialize in meeting unique demands and aligning our development with your needs. We have a track record of developing crucial vacuum components that are difficult for others, drawing on our extensive experience. Please feel free to consult with us.The Lineup of related components usable inside vacuum containersOur products cater to a wide range of fields and demanding conditions, including probes, cables, and connectors that support high current and high voltage applications.

Specifications Acceptable Plug Diameter

0.063 in | 1.6 mm

Specifications Materials

Alumina | Polyetheretherketone (PEEK) | Polytetrafluoroethylene (PTFE)

Specifications Number Of Pins

4 | 8 | 12 | 19 | 22 | 30 | 48

Specifications Operating Temperature

-55 to 150 ºC

Specifications Type

Burndy/Souriau Type Relay Insulation Insert
