Gruenberg designs and manufactures a complete line of standard and custom industrial cabinet ovens to accommodate a variety of thermal processing applications up to 1200°F, which are ideally suited for annealing, aging, core hardening, drying, preheating, curing, and component testing. With additional options, they can also be used for applications such as epoxy, plastic, and rubber curing; paint and varnish baking; textile drying; and sterilizing.
Product Specifications
Specifications Air Flow
Horizontal
Specifications Circulation
4800 CFM
Specifications Exterior Depth
62 in | 157.5 cm
Specifications Exterior Height
120 in | 304.8 cm
Specifications Exterior Width
78 in | 198.1 cm
Specifications Gruenberg Industrial Oven Features
chamber so there is no radiant influence on the work in process | CHIL construction ensures minimal heat transfer from oven chamber to the exterior | Energy-efficient, Incoloy® sheathed, seamless tubular heaters | Heating elements are suspended in the plenum, which is adjacent to the process | Heavy-duty, fully welded structural steel frame | Insulation is moisture-proof, non-combustible, non-settling, and asbestos-free | Lid is constructed using a structural steel frame to ensure sealing integrity | Removable side and back walls for easy clean-up and maintenance
Specifications Heater Wattage
30 kW
Specifications Insulation Thickness Inches
4-low
Specifications Interior Depth
48 in | 121.9 cm
Specifications Interior Height
72 in | 182.9 cm
Specifications Interior Volume
96 ft³
Specifications Interior Width
48 in | 121.9 cm
Specifications Maximum Temperature
450 ºF
Specifications Shipping Weight
3000 lb
