Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

SKU:PUS-e3c61a

Versatile Cablecraft Unidrum Lever Control Cables for precise and efficient light lever controls.

Regular price $129.99
Regular price Sale price $129.99
Sale

Initiate Order

Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

$129.99

Quantity: 1

Claim Your Seller Account

Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

$129.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Cablecraft Unidrum Lever Control Cables combine precision engineering with versatility, offering a variety of applications for light lever controls. With options for different cable exit positions, output end configurations, and very light-duty wire rope dia, these cables provide reliable and smooth operation. Featuring an approximate 135° lever travel and an overall length of 120", they ensure efficient control and performance in utility applications. The threaded swivel output end configuration further enhances flexibility and ease of use.

Product Specifications

Specifications Cable Exit Position
CableCraft Unidrum Lever Upper Mount, Left Exit
Specifications Cable Travel
3 "
Specifications Knob Color
Black 165-505-101
Specifications Lever Travel
Approx. 135º
Specifications Output End Configuration
Threaded Swivel
Specifications Overall Length In
120 "
Specifications Swivel Dimension A Per Stroke
2 to 6.94 "
Specifications Swivel Dimension A Per Stroke Extended
3 to 8.94 "
Specifications Type
Utility
Specifications Wire Rope Dia
Very Light Duty
CAGE
0T9L4
NAICS
332510
PSC
4030
