Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

SKU:PUS-22a576

Precision and durability in control cables for varied applications. Red knob, grooved cap, very light duty wire rope, and 90° lever travel.

Regular price $89.99
Regular price Sale price $89.99
Sale

Initiate Order

Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

$89.99

Quantity: 1

Claim Your Seller Account

Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

$89.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Cablecraft® Unidrum Lever Control Specialty Cables provide precise and reliable control for a variety of applications, featuring a red knob for easy identification and a grooved cap output end configuration. With a very light duty wire rope and an approximate 90° lever travel, these cables offer flexibility and durability. Measuring 120 inches in overall length, they ensure smooth operation with swivel dimensions ranging from 2 to 8.94 inches per stroke, making them ideal for light lever controls in diverse settings.

Product Specifications

Specifications Cable Exit Position
CableCraft Unidrum Lever Lower Mount, Left Exit
Specifications Cable Travel
2 "
Specifications Knob Color
Red 165-505-102
Specifications Lever Travel
Approx. 90º
Specifications Output End Configuration
Grooved Cap
Specifications Overall Length In
120 "
Specifications Swivel Dimension A Per Stroke
2 to 6.94 "
Specifications Swivel Dimension A Per Stroke Extended
3 to 8.94 "
Specifications Type
Bristow®
Specifications Wire Rope Dia
Very Light Duty
CAGE
0T9L4
NAICS
332510
PSC
4030
