Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

SKU:PUS-fce70b

Enhance control with Cablecraft Unidrum Lever Control Cables. Versatile, durable, and precise for various applications.

Regular price $69.99
Regular price Sale price $69.99
Sale

Initiate Order

Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

$69.99

Quantity: 1

Claim Your Seller Account

Cablecraft Unidrum Lever Control Cables

Cablecraft Unidrum Lever Control Cables

$69.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Cablecraft® Unidrum Lever Control Specialty Cables offer precise and reliable control for a variety of applications. With optional lever/cable combinations, these cables are perfect for light lever controls. The black knob and Threaded Cap output end configuration ensure ease of use and durability. With an overall length of 120 inches, very light duty wire rope, and swivel dimensions per stroke ranging from 2 to 9.18 inches, these cables provide smooth operation and flexibility. Ideal for institutions seeking quality and performance in cable controls.

Product Specifications

Specifications Cable Exit Position
CableCraft Unidrum Lever Upper Mount, Left Exit
Specifications Cable Travel
2 "
Specifications Knob Color
Black 165-505-101
Specifications Lever Travel
Approx. 90º
Specifications Output End Configuration
Threaded Cap
Specifications Overall Length In
120 "
Specifications Swivel Dimension A Per Stroke
2 to 7.18 "
Specifications Swivel Dimension A Per Stroke Extended
3 to 9.18 "
Specifications Type
Bristow®
Specifications Wire Rope Dia
Very Light Duty
CAGE
0T9L4
NAICS
332510
PSC
4030
