Carbon Steel CSK Head Lock Bolt - 2.583in Maximum Mandrel Length

Name: Carbon Steel CSK Head Lock Bolt - 2.583in Maximum Mandrel Length
Brand: Ornit USA
SKU: STA-dc800e
Price: 12.99 USD
Availability: OutOfStock

SKU:STA-dc800e

Premium Carbon Steel CSK Head Lock Bolt - 2.583in, Zinc Finish. Reliable & durable for secure fastening in diverse applications.

$12.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Enhance your assembly projects with this premium Carbon Steel CSK Head Lock Bolt featuring a 2.583in maximum mandrel length. Made by Ornit with a 90 Countersunk (CSK) head, zinc finish, and meeting stringent tensile and shear strength standards, this bolt ensures reliability and durability. With precise dimensions and a grip range of 1.00in to 1.125in, it offers secure fastening for various applications.

Product Specifications

Dimensions Diameter

1/4 in

Dimensions Dimension A

0.254 to 0.259 in

Dimensions Maximum Grip Range

1.00 in

Dimensions Maximum Head Diameter

0.525 in

Dimensions Maximum Hole Diameter

0.266 in

Dimensions Maximum Hole Size

0.266 in

Dimensions Maximum Length

2.696 in

Dimensions Maximum Mandrel Length

2.583 in

Dimensions Minimum Grip Range

1.125 in

Dimensions Minimum Head Diameter

0.475 in

Dimensions Minimum Hole Diameter

0.256 in

Dimensions Minimum Length

2.559 in

Dimensions Minimum Mandrel Length

2.458 in

Dimensions Minimum Shear Strength

1383 in

Dimensions Minimum Tensile Strength

1361 in

Dimensions Nominal Drill Side

0.261 in

Dimensions Nominal Head Diameter

0.500 in

Dimensions Nominal Mandrel Length

2.521 in

Technical Specs Brands

Ornit

Technical Specs Finish

Zinc

Technical Specs Head B

0.437 to 0.473 in

Technical Specs Head C

0.101 to 0.113 in

Technical Specs Head Shape

90 Countersunk (CSK) Head

Technical Specs Material

Carbon Steel
