Carbon Steel Wing Nut Hydraulic Plug, 1 Inch

Name: Carbon Steel Wing Nut Hydraulic Plug, 1 Inch
Brand: Seal Fast, Inc.
SKU: COU-96d75a
Price: 24.99 USD
Availability: OutOfStock

SKU:COU-96d75a

High-performance 1-inch Carbon Steel Wing Nut Hydraulic Plug for secure and quick connections in hydraulic systems.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Carbon Steel Wing Nut Hydraulic Plug features a 1-inch body size, designed for durability and high performance in hydraulic applications. Made from robust carbon steel, this plug ensures secure connections with a working pressure of 2900 psi and a wide temperature range from -4 to +176 ºF. The wing nut design allows for quick and easy connections, making it ideal for various applications such as oil well equipment, sand and salt spreaders, and dump trailers. Interchangeable with well-known brands, this hydraulic plug is a reliable solution for efficient and low-spill coupling needs.

Product Specifications

Applications

Seal Fast Wing Nut Quick Connects/Disconnects are low spill couplings designed to allow connection under pressure. They are recommended for oil well equipment, sand and salt spreaders, live bottom trailers, dump trailers, etc.

Specifications Body Size

1 in

Specifications End Size

1 in. Male NPT

Specifications Features

Wing Nuts

Specifications Hex Size

1.88 in

Specifications Interchangeable With

Parker 6100Snap-Tite 78Aeroquip 5100Dixon W

Specifications Material

Carbon Steel

Specifications Overall Length

3.55 in

Specifications Shape

Male

Specifications Style

Hydraulic Plugs

Specifications Working Pressure

2900 psi

Specifications Working Temperature Range

-4 to +176 ºF

Specifications Wrench Flat Size

1.56 in

Carbon Steel Wing Nut Hydraulic Plug, 1 Inch
