Century+ Series High Voltage Sealed Rear Mount Receptacle
Century+ Series High Voltage Sealed Rear Mount Receptacle
SKU:HIG-d103bc
Experience high voltage reliability with Century+ Receptacle: Sealed, Threaded, and Rear Mount. Ideal for Laser Gyroscopes & more.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Century+ Series High Voltage Sealed Rear Mount Receptacle
$59.99
Quantity: 1
Claim Your Seller Account
Century+ Series High Voltage Sealed Rear Mount Receptacle
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Century+ Series Receptacle is a high-quality threaded rear mount solution designed to meet stringent institutional requirements. With a robust interface seal and an 18 kVDC rating, this receptacle is ideal for specialized applications like Laser Gyroscopes and Radar power supplies. Available in both plastic and high alumina ceramic options, it offers reliable performance in extreme conditions. The silicone rubber seal ensures a secure connection, while the standardized design guarantees compatibility with Century Plus series threaded plug cable assemblies.
Product Specifications
Body Properties Coupling Nut Material
N/A | Stainless Steel
Contact Properties Contact Diameter
0.030
Contact Properties Contact Material
Brass/Au
Contact Properties Contact Size
22
Contact Properties Contact Type
Male
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Receptacle Bag Assembly
Specifications Braid Termination
N/A
Specifications Coupling Style
Threaded
Specifications Current Rating
TBD
Specifications Current Rating Rms
12 A
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic or Ceramic
Specifications Interface Seal
Silicone Rubber
Specifications Mating Compatibility
Mates Century Plus series threaded plug cable assemblies.
Specifications Mating Torque
5 to 6 in-lbs
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Rear Mount
Specifications Panel Mounting Torque
8 to 10 in-lbs
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
Yes
Specifications Series
Century+
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
25 kVDC at 70,000 ft. (simulated) at ambient temperature
Specifications Voltage Rating
18 kVDC
Specifications Wire Insulation
N/A
