Chassis Mount Circuit Board Support Screws (75 & 75M4 Series)
Chassis Mount Circuit Board Support Screws (75 & 75M4 Series)
SKU:01C-89d950
Chassis Mount Circuit Board Support Screws: .156 Board Hole, Threaded, Nylon 66 Material, Pack of 1000, RoHS Compliant, -40 to 185F Temp Range
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Chassis Mount Circuit Board Support Screws (75 & 75M4 Series)
$49.99
Quantity: 1
Claim Your Seller Account
Chassis Mount Circuit Board Support Screws (75 & 75M4 Series)
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your circuit board assembly with the Chassis Mount Circuit Board Support Screws. These female-threaded supports feature a .156 PCB mounting hole for secure attachment, offering a snap-fit design for easy installation. Each pack contains 1000 screws made of durable Nylon 66 UL94V-2 material (UL94V-0 option available). Compliant with ASTM D 4066 and PA111 standards, RoHS compliant, and with a temperature range of -40 to 185F (-40 to 85C), these screws ensure reliable performance in various environments.
Product Specifications
Specifications Dim L
.875 (22.2) inches (mm)
Specifications Thread Size
M4
