Check Valves with Fluorocarbon Seal and Metal Construction

Name: Check Valves with Fluorocarbon Seal and Metal Construction
Brand: O'Keefe Controls Co.
SKU: CHE-178c96
Price: 29.99 USD
Availability: OutOfStock

SKU:CHE-178c96

High-performance Check Valves with Fluorocarbon Seal and metal construction for industrial reliability.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Our Check Valves with Fluorocarbon Seal and metal construction are designed for reliable performance in various industrial applications. With a Seal Material of Fluorocarbon and Ball Material of 303 SS, these valves offer a Nominal Orifice Size of 0.031 inches and a Maximum Operating Pressure of 875 kPa. The all-metal construction ensures long life operation and cost-effectiveness, making them ideal for institutional buyers seeking durability and efficiency.

Product Specifications

Dimensions Nose Diameter

5.59 mm

Dimensions Orifice Diameter

0.031 in | 0.79 mm

Dimensions Thread Size

Dimensions Total Length

16.3 mm

Dimensions Width Across Flats Hex

4 mm

Features Features

All metal construction option Long life operation Low cost

Specifications Ball Material

Fluorocarbon

Specifications Connection A

M8 Threaded Insert O-Ring seal

Specifications Cv

0.022

Specifications Hex Type

Internal

Specifications Material

303 SS

Specifications Maximum Operating Pressure

875 kPa

Specifications Maximum Temperature

120 ÂºF

Specifications Nominal Orifice Size

Specifications Screened

None

Specifications Seal Material

Fluorocarbon

Specifications Seat Leakage

6 SCCM (max.) air flow at greater than 50 psi differential

Specifications Thread

Male
