Introducing the ChemResist PPS Sheet, engineered with unparalleled chemical resistance and dimensional stability. Our PPS sheets are ideal for precise machining, with minimal moisture absorption and exceptional electrical characteristics. Compliant with ASTM D 6358 and UL 94 V0 flammability rating, these sheets are perfect for applications in pump housings, chromatography components, and more. With a high heat deflection temperature of 250°F and a maximum operating temperature of 425°F, the ChemResist PPS Sheet is the ultimate choice for demanding environments.
Product Specifications
Advantages 0
High Strength.Excellent chemical & hydrolysis resistance.Very good dimensional stability.Excellent wear & frictional behavior.Inherent low flammability. Excellent alternative to PEEK at lower temperatures.Good electrical insulating & dielectric properties.Essentially zero moisture absorption.
Applications 0
Pump housings.High pressure liquid Chromatography components.Chip nests.Retaining rings.Wafer Carriers.Laboratory & Analytical Equipment.
Specifications Astm Shape Spec
ASTM D 6358
Specifications Availability
3-4 weeks
Specifications Coefficient Of Friction Dynamic
.40
Specifications Color
Off-white
Specifications Dielectric Strength
540 V/mil
Specifications Flammability Rating Ul 94
V0 (.125")
Specifications Flexural Modulus
575000 psi
Specifications Flexural Strength
21000 psi
Specifications Hardness Durometer Shore D
85
Specifications Heat Deflection Temperature 264 Psi
250 ºF
Specifications Impact Strength Notched
.60 ft·lb/in
Specifications Material
PPS
Specifications Maximum Operating Temperature
425 ºF
Specifications Minimum Order
1
Specifications Optional Sheet Size
12"x48"⢠24"x48"
Specifications Sheet Size
12 x 12 in
Specifications Specific Gravity
1.35
Specifications Tensile Strength
13500 psi
Specifications Thickness
2.500 in
Specifications Tolerance
+only in
Specifications Weight
1.76 lb/ft²
