Chicago Hardware 1-1/2" Drop Forged Screw Pin Anchor Shackle

Chicago Hardware 1-1/2" Drop Forged Screw Pin Anchor Shackle

SKU:WIR-15bbd3

Chicago Hardware 1-1/2" Drop Forged Screw Pin Anchor Shackle - Heavy-duty, USA-made, 17-ton WLL, compliant with Federal standards

Regular price $1,899.99
Regular price Sale price $1,899.99
Sale

Initiate Order

Chicago Hardware 1-1/2" Drop Forged Screw Pin Anchor Shackle

Chicago Hardware 1-1/2" Drop Forged Screw Pin Anchor Shackle

$1,899.99

Quantity: 1

Claim Your Seller Account

Chicago Hardware 1-1/2" Drop Forged Screw Pin Anchor Shackle

Chicago Hardware 1-1/2" Drop Forged Screw Pin Anchor Shackle

$1,899.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Chicago Hardware Drop Forged Screw Pin Anchor Shackle is a heavy-duty wire rope hardware essential, proudly made in the USA. With a working load limit of 17 tons and precision-engineered dimensions including a 2-3/8" width at eyes and 1-5/8" pin diameter, this self-colored shackle excels in robust performance and durability. Ideal for industrial applications, this Screw Pin Shackle meets stringent Federal/DoD procurement standards, ensuring reliability in the most demanding environments.

Product Specifications

Specifications Od Eyes D
3-1/2"
Specifications Pin Or Bolt Diameter E
1-5/8"
Specifications Size Dia
1-1/2"
Specifications Width Eyes A
2-3/8"
Specifications Wll
17 Ton
Specifications Wt Per 100 Pcs Lbs
1777.5
CAGE
0T9L4
NAICS
332999
PSC
5340
