Chicago Hardware & Fixture Co. 1/4" Self Colored Screw Pin Anchor Shackle

Name: Chicago Hardware & Fixture Co. 1/4" Self Colored Screw Pin Anchor Shackle
Brand: Lexco Cable Manufacturing
SKU: WIR-bd0b3e
Price: 129.99 USD
Availability: OutOfStock

SKU:WIR-bd0b3e

Chicago Hardware & Fixture Co. 1/4" Self Colored Screw Pin Anchor Shackle - Heavy-duty, USA-made shackle with 1/2 Ton WLL. Exceptionally strong and durable for rigorous applications.

$129.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Chicago Hardware & Fixture Co. 1/4" Self Colored Screw Pin Anchor Shackle is a robust and reliable shackling solution designed for heavy-duty applications. With a Working Load Limit (WLL) of 1/2 Ton, this drop forged shackle offers exceptional strength and durability. Made in the USA, it features precise specifications including a Size Dia of 1/4", Width @ Eyes A of 15/32", O.D. Eyes D of 3/4", and Pin or Bolt Diameter E of 5/16". Each piece weighs 13.5 lbs per 100 units, ensuring quality and performance that meet the stringent requirements of government and institutional buyers.

Product Specifications

Specifications Od Eyes D

3/4"

Specifications Pin Or Bolt Diameter E

5/16"

Specifications Size Dia

1/4"

Specifications Width Eyes A

15/32"

Specifications Wll

1/2 Ton

Specifications Wt Per 100 Pcs Lbs

13.5

CAGE

0T9L4

NAICS

332999

PSC

5340

Chicago Hardware & Fixture Co. 1/4" Self Colored Screw Pin Anchor Shackle
