Chicago Hardware & Fixture Co. 8-1/2 Ton Drop Forged Screw Pin Anchor Shackle

Name: Chicago Hardware & Fixture Co. 8-1/2 Ton Drop Forged Screw Pin Anchor Shackle
Brand: Lexco Cable Manufacturing
SKU: WIR-0d8c04
Price: 699.99 USD
Availability: OutOfStock

SKU:WIR-0d8c04

Heavy-duty 1" Screw Pin Anchor Shackle - 8-1/2 Ton WLL, Made in USA, Chicago Hardware & Fixture Co.

$699.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Chicago Hardware & Fixture Co. Screw Pin Self Colored is a robust 1" diameter shackle with an impressive Working Load Limit (WLL) of 8-1/2 Ton. Crafted in the USA, this shackle features a Width @ Eyes A of 1-11/16" and an O.D. Eyes D of 2-1/2" for secure connections. The Pin Diameter E is 1-1/8", providing strength and reliability. With a weight of 537.5 lbs per 100 pieces, this shackle is ideal for heavy-duty applications, ensuring safety and durability.

Product Specifications

Specifications Od Eyes D

2-1/2"

Specifications Pin Or Bolt Diameter E

1-1/8"

Specifications Size Dia

Specifications Width Eyes A

1-11/16"

Specifications Wll

8-1/2 Ton

Specifications Wt Per 100 Pcs Lbs

537.5

CAGE

0T9L4

NAICS

332999

PSC

5340
