Chromoly Steel Rod Ends - Female Thread, Left Variant
Chromoly Steel Rod Ends - Female Thread, Left Variant
SKU:ROD-62241b
Premium Chromoly Steel Rod Ends for automotive and industrial use. High strength, heat-treated, and PTFE lined for durability.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Chromoly Steel Rod Ends - Female Thread, Left Variant
$29.99
Quantity: 1
Claim Your Seller Account
Chromoly Steel Rod Ends - Female Thread, Left Variant
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your automotive, industrial, and machinery projects with our Chromoly Steel Rod Ends. Crafted with precision using Chromoly Steel and 52100 Bearing Steel, these rod ends offer exceptional strength and durability. Featuring a Black Oxide Coating, Heat Treatment, and PTFE Lining, they ensure smooth operations and longevity. With specifications meeting UNF 3A Thread Standards, HRC58-64 Hard Chrome Plating, and a Static Radial Load capacity of 16,240 lbs, our rod ends guarantee reliability in diverse applications.
Product Specifications
Specifications Approx Weight
0.43 lbs
Specifications A Length 0015 0015
2.625 in
Specifications A Mis Angle Ref
65
Specifications Ball Material
52100 Bearing Steel, Heat Treated Hrc58-64 Hard Chrome Plated
Specifications Body Material
Chromoly Steel, Heat Treated, Black Oxide Coated
Specifications B Dia 00025 00005
0.5000 in
Specifications C Length 0062 0031
1.375 in
Specifications D Dia 0010 0010
1.500 in
Specifications Liner Material
Ptfe Lined Optional, Add "T" To Suffix
Specifications N Thread Unf 3a
1/2-20
Specifications Rod End Variants
RCHM-8T
Specifications Static Radial Load
16,240 lbs
Specifications Thread Type
Left
Specifications Type
Female
Specifications Warning
Prop 65 Warning: This product may contain chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Specifications W Width 0005 0005
1.250 in
