Chromoly Steel Rod Ends for Automotive and Industrial Applications
Chromoly Steel Rod Ends for Automotive and Industrial Applications
SKU:ROD-a230be
Durable Chromoly Steel Rod Ends for automotive and industrial applications. Reliable performance with high load capacity and PTFE lining.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Chromoly Steel Rod Ends for Automotive and Industrial Applications
$45.99
Quantity: 1
Claim Your Seller Account
Chromoly Steel Rod Ends for Automotive and Industrial Applications
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your automotive and industrial machinery with our Chromoly Steel Rod Ends. Made from heat-treated Chromoly Steel with Black Oxide Coating and 52100 Bearing Steel ball material, these rod ends are durable and reliable. With a static radial load capacity of 29,127 lbs, PTFE lined for smooth operation, and meeting stringent industry standards, these rod ends are ideal for heavy-duty use in various industries.
Product Specifications
Specifications Approx Weight
0.84 lbs
Specifications A Length 0015 0015
3.375 in
Specifications A Mis Angle Ref
61
Specifications Ball Material
52100 Bearing Steel, Heat Treated Hrc58-64 Hard Chrome Plated
Specifications Body Material
Chromoly Steel, Heat Treated, Black Oxide Coated
Specifications B Dia 00025 00005
0.7500 in
Specifications C Length 0062 0031
1.785 in
Specifications D Dia 0010 0010
2.000 in
Specifications Liner Material
Ptfe Lined Optional, Add "T" To Suffix
Specifications N Thread Unf 3a
3/4-16
Specifications Rod End Variants
RCHM-12T
Specifications Static Radial Load
29,127 lbs
Specifications Thread Type
Left
Specifications Type
Female
Specifications Warning
Prop 65 Warning: This product may contain chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Specifications W Width 0005 0005
1.500 in
