Chromoly Steel Rod Ends - Industrial Grade
Chromoly Steel Rod Ends - Industrial Grade
SKU:ROD-7cf222
Enhance your machinery with our durable Chromoly Steel Rod Ends - perfect for automotive and industrial applications.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Chromoly Steel Rod Ends - Industrial Grade
$24.99
Quantity: 1
Claim Your Seller Account
Chromoly Steel Rod Ends - Industrial Grade
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your automotive vehicles and industrial machines with our Chromoly Steel Rod Ends. Made from heat-treated Chromoly Steel with a Black Oxide coating and 52100 Bearing Steel ball material, these rod ends offer exceptional durability and performance. Featuring PTFE lining and precision engineering, these rod ends ensure smooth operation and reliable load-bearing capabilities. Commonly used across various industries. Thread Type: Left. Dimensions: B: 0.6250 in, D: 1.750 in, W: 1.375 in, A: 2.875 in. Meet industry-leading standards for quality and performance.
Product Specifications
Specifications Approx Weight
0.57 lbs
Specifications A Length 0015 0015
2.875 in
Specifications A Mis Angle Ref
64
Specifications Ball Material
52100 Bearing Steel, Heat Treated Hrc58-64 Hard Chrome Plated
Specifications Body Material
Chromoly Steel, Heat Treated, Black Oxide Coated
Specifications B Dia 00025 00005
0.6250 in
Specifications C Length 0062 0031
1.562 in
Specifications D Dia 0010 0010
1.750 in
Specifications Liner Material
Ptfe Lined Optional, Add "T" To Suffix
Specifications N Thread Unf 3a
5/8-18
Specifications Rod End Variants
RCHM-10T
Specifications Static Radial Load
21,219 lbs
Specifications Thread Type
Left
Specifications Type
Female
Specifications Warning
Prop 65 Warning: This product may contain chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Specifications W Width 0005 0005
1.375 in
