Chromoly Steel Rod Ends - Industrial Grade Female Variant
Chromoly Steel Rod Ends - Industrial Grade Female Variant
SKU:ROD-f23028
Enhance your industrial machinery with durable Chromoly Steel Rod Ends.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Chromoly Steel Rod Ends - Industrial Grade Female Variant
$24.99
Quantity: 1
Claim Your Seller Account
Chromoly Steel Rod Ends - Industrial Grade Female Variant
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your machinery with our Chromoly Steel Rod Ends designed for industrial applications. These rod ends feature Chromoly Steel bodies, heat-treated and black oxide coated for durability. The 52100 Bearing Steel balls are heat treated and hard chrome plated with PTFE lining. With precise specifications, UNF 3A threaded, and capable of withstanding a static radial load of 29,127 lbs, these rod ends ensure reliable performance in automotive vehicles and industrial machines. Compliant with industry standards for quality assurance.
Product Specifications
Specifications Approx Weight
0.84 lbs
Specifications A Length 0015 0015
3.375 in
Specifications A Mis Angle Ref
61
Specifications Ball Material
52100 Bearing Steel, Heat Treated Hrc58-64 Hard Chrome Plated
Specifications Body Material
Chromoly Steel, Heat Treated, Black Oxide Coated
Specifications B Dia 00025 00005
0.7500 in
Specifications C Length 0062 0031
1.785 in
Specifications D Dia 0010 0010
2.000 in
Specifications Liner Material
Ptfe Lined Optional, Add "T" To Suffix
Specifications N Thread Unf 3a
3/4-16
Specifications Rod End Variants
RCHPM-12T
Specifications Static Radial Load
29,127 lbs
Specifications Thread Type
Right
Specifications Type
Female
Specifications Warning
Prop 65 Warning: This product may contain chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Specifications W Width 0005 0005
1.500 in
