Chromoly Steel Rod Ends - Industrial-Grade Rod End Bearings
Chromoly Steel Rod Ends - Industrial-Grade Rod End Bearings
SKU:ROD-3cabbd
Premium Chromoly Steel Rod Ends for automotive & industrial use, durable and versatile. Enhance your machinery efficiency now!
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Chromoly Steel Rod Ends - Industrial-Grade Rod End Bearings
$24.99
Quantity: 1
Claim Your Seller Account
Chromoly Steel Rod Ends - Industrial-Grade Rod End Bearings
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your machinery with our Chromoly Steel Rod Ends. Made of high-quality Chromoly Steel and 52100 Bearing Steel, heat-treated for durability. Black Oxide coated body ensures corrosion resistance. PTFE lined for smooth operation. Available in various configurations. Ideal for automotive, industrial, and diverse applications.
Product Specifications
Specifications Approx Weight
0.57 lbs
Specifications A Length 0015 0015
2.875 in
Specifications A Mis Angle Ref
64
Specifications Ball Material
52100 Bearing Steel, Heat Treated Hrc58-64 Hard Chrome Plated
Specifications Body Material
Chromoly Steel, Heat Treated, Black Oxide Coated
Specifications B Dia 00025 00005
0.6250 in
Specifications C Length 0062 0031
1.562 in
Specifications D Dia 0010 0010
1.750 in
Specifications Liner Material
Ptfe Lined Optional, Add "T" To Suffix
Specifications N Thread Unf 3a
5/8-18
Specifications Rod End Variants
RCHPM-10T
Specifications Static Radial Load
21,219 lbs
Specifications Thread Type
Right
Specifications Type
Female
Specifications Warning
Prop 65 Warning: This product may contain chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Specifications W Width 0005 0005
1.375 in
