The CHT Viscous Liquid RTV Silicone Adhesive Sealant is a high-performance one-part adhesive sealant designed to meet the stringent requirements of MIL A-46146B Group 1 Type 11UL certification. This translucent adhesive offers excellent adhesion to a wide range of substrates and features a self-leveling, flowable rheology. With a working temperature range from -62°C to +200°C, it provides durability and reliability in various environments. Additionally, this RTV silicone sealant includes UV trace for easy detection and complies with industry standards for quality and performance.
Product Specifications
Features
Meets the requirements of MIL A-46146B Group 1 Type 11UL certified under file No. E334038Excellent adhesion to most substratesContains UV trace for easy detection
Specifications Appearance
Viscous Liquid
Specifications A Part Viscosity
40000 MPa
Specifications Coefficient Of Thermal Expansion Cte Linear
294 ppm/ºC
Specifications Coefficient Of Thermal Expansion Cte Volumetric
883 ppm/ºC
Specifications Color
Translucent
Specifications Cure Type
Alkoxy
Specifications Dielectric Constant At 1 Kilohertz Khz Frequency
2.6
Specifications Dielectric Strength
18 kV/mm
Specifications Dissipation Factor At 1 Kilohertz Khz Frequency
0.0031
Specifications Durometer Shore A
27 duro
Specifications Elongation
400 %
Specifications Food And Drug Administration Fda
No
Specifications Maximum Cure Time At 25 Degree Celsius C Temperat
72 hours
Specifications Maximum Storage Temperature
40 ºC
Specifications Maximum Working Temperature
+200 ºC
Specifications Minimum Working Temperature
-62 ºC
Specifications Non Corrosive
Yes
Specifications Pack Type
1 Part
Specifications Rheology
Flowable
Specifications Room Temperature Vulcanizing Rtv Or Heat Cure
Room Temperature Vulcanizing (RTV)
Specifications Self Bonding
Yes
Specifications Sg
1.03
Specifications Shelf Life
6 months
Specifications Tack Free Time
18 minutes
Specifications Tensile Strength
2.5 MPa
Specifications Test Conditions
After 7 days cure at 23º+/-2ºC and 50+/-5% humidity
Specifications Thermal Conductivity
0.18 W/m·K
Specifications Underwriters Laboratories Ul 94v 0
No
Specifications Volume Resistivity
2.25 E+15 Ω·cm
