Cincoze 19" Industrial Panel PC with Intel Core i5 Processor
Cincoze 19" Industrial Panel PC with Intel Core i5 Processor
SKU:IND-080285
Transform your industrial operations with the Cincoze 19" Industrial Panel PC - Intel Core i5 Processor, DDR5 Memory, and Projected Capacitive Touch.
Regular price
$1,799.99
Regular price
Sale price
$1,799.99
Unit price
per
Initiate Order
Cincoze 19" Industrial Panel PC with Intel Core i5 Processor
$1,799.99
Quantity: 1
Claim Your Seller Account
Cincoze 19" Industrial Panel PC with Intel Core i5 Processor
$1,799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience the power and reliability of the Cincoze CO-119C-R10/P2202-i5-R10 19" Industrial Panel PC. Featuring an onboard 12th Gen Intel Core i5-1245UE Processor, 2x DDR5 SO-DIMM sockets supporting up to 64GB memory, and a modular design with projected capacitive touch technology. This rugged panel PC is built for demanding industrial environments, boasting a fanless design, wide operating temperature range, and IP65-rated construction ensuring durability and performance under harsh conditions.
Product Specifications
Additional Information Additional Information
Cincoze® open-frame high-performance industrial panel PC (CO-100/P2202) is equipped with an Intel® Core⢠U-series (Alder Lake-P) processor, rich I/O interfaces (1 GbE LAN, USB 3.2 Gen 2x1, COM, DIO, etc.), and flexible expansion. The biggest highlight is its adjustable mounting bracket design (Patent No.: D224544, D224545, I802427) that allows flexible adjustment and multi-stage locking to greatly improve the convenience of installation, effectively reducing the degree of customization required when integrating with equipment. It is purpose-built for equipment manufacturers.Excellent Computing PerformanceThe CO-100/P2202 series is equipped with the 12th Gen Intel® Core⢠i5/i3 U-series (Alder Lake-P) processor based on the Intel® 7 process. The U-series has a low power consumption of only 15W, boasts excellent performance with up to 10 Cores (2P+8E), and includes the built-in Intel® Iris® Xe graphics to easily handle image classification inference performance in AI deep learning.CDS Patented TechnologyCincoze® Convertible Display System (CDS) patented technology makes field-side maintenance and future upgrades easier. Replacing a display or improving system performance only requires replacing a single component, which significantly cuts upgrade costs.Patent No. M482908Easy to InstallThe exclusive adjustable mounting bracket (Patent No.: I802427) has thickness adjustment options and supports multiple locking methods (panel and boss types), providing a simpler and more convenient integration for industrial machines using flat mount and standard mount.Patent No.: D224544, D224545, I802427Integrated StructureThe flexible and reliable design of the open-frame architecture enables deployment in equipment machines, and after removing the mounting bracket can be installed directly using the VESA mount for standalone use, or installed in a 19â rack for display function.Rugged, Safe, ReliableThe CO-100/P2202 series features a series of industrial-grade protections, such as a fanless design, wide operating temperature range (0°C to 60°C), wide range DC power input (9 to 48VDC), and IP65 dustproof/water resistant front panel for field-side HMI applications in harsh industrial environments.
Audio Audio Codec
Realtek® ALC888, High Definition Audio
Audio Line Out
1x Line-Out, Phone Jack 3.5 mm
Audio Mic In
1x Mic-in, Phone Jack 3.5 mm
Co 119c Backlight Mean Time Between Failures Mtbf Co 119c
50,000 h
Co 119c Brightness Co 119c
350 cd/m²
Co 119c Compliances Co 119c
Front Panel Ingress Protection (IP65)
Co 119c Construction Co 119c
One-Piece and Slim Bezel Design
Co 119c Contrast Ratio Co 119c
1000 :1
Co 119c Depth Co 119c
397.5 mm
Co 119c Electromagnetic Compatibility Emc Co 119c
European Conformity (CE) | Federal Communications Commission (FCC) | Interference-Causing Equipment Standard 003 (ICES-003 Class A) | United Kingdom Conformity Assessed (UKCA)
Co 119c Electromagnetic Interference Emi Co 119c
CISPR 32 Conducted & Radiated: Class AEN/BS EN 55032 Conducted & Radiated: Class AEN/BS EN IEC 61000-3-2 Harmonic current emissions: Class AEN/BS EN61000-3-3 Voltage fluctuations & flickerFCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
Co 119c Environmental Management System Ems Co 119c
EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kVEN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/mEN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kVEN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kVEN/IEC 61000-4-6 CS: 3VEN/IEC 61000-4-8 PFMF: 50 Hz, 1A/mEN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz
Co 119c Height Co 119c
63 mm
Co 119c Liquid Crystal Display Lcd Color Co 119c
16.7M
Co 119c Liquid Crystal Display Lcd Size Co 119c
19 in | 5:4
Co 119c Maximum Resolution Co 119c
1280 x 1024
Co 119c Mounting Bracket Co 119c
Pre-installed Mounting Bracket with Adjustable Design (Support 11 different stages of adjustment)
Co 119c Mounting Type Co 119c
Flat | Rack Mount | Standard | Video Electronics Standards Association (VESA)
Co 119c Non Condensing Relative Humidity Rh At 50 Degree Celsius
80 %
Co 119c Operating Temperature Co 119c
0 to 50 ºC
Co 119c Pixel Pitch Horizontal Co 119c
0.294 mm
Co 119c Pixel Pitch Vertical Co 119c
0.294 mm
Co 119c Storage Temperature Co 119c
-20 to 60 ºC
Co 119c Touchscreen Type Co 119c
Projected Capacitive Touch
Co 119c Viewing Angle Horizontal Vertical H V Co 119c
170/160
Co 119c Weight Co 119c
6.91 kg
Co 119c Width Co 119c
472.8 mm
Environment Electromagnetic Compatibility Emc
CE, UKCA, FCC, ICES-003 Class AEN IEC 61000-6-4, EN IEC 61000-6-2 (24VDC Input Only)
Environment Electromagnetic Interference Emi
CISPR 32 Conducted & Radiated: Class AEN/BS EN 55032 Conducted & Radiated: Class AEN/BS EN IEC 61000-3-2 Harmonic current emissions: Class AEN/BS EN61000-3-3 Voltage fluctuations & flickerFCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
Environment Environmental Management System Ems
EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kVEN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 10 V/mEN/IEC 61000-4-4 EFT: AC Power: 2 kV; DC Power: 1 kV; Signal: 1 kVEN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kVEN/IEC 61000-4-6 CS: 10VEN/IEC 61000-4-8 PFMF: 50 Hz, 30A/mEN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 1 cycles at 60 Hz
Physical Depth
190 mm
Physical Height
41.5 mm
Physical Width
254.5 mm
Power Power Button
1x ATX Power On/Off Button
Power Power Input
9 to 48 VDC, 3-Pin Terminal Block
Power Power Mode Switch
1x AT/ATX Mode Switch
Power Remote Power Onoff
1x Remote Power On/Off, 2-pin Terminal Block
Reliability And Protection Over Voltage Protection
Protection Range: 51~58VProtection Type: shut down operating voltage, re-power on at the present level to recover
Reliability And Protection Reverse Power Input Protection
Yes
