Cincoze CS-117C Sunlight Readable Panel PC
Cincoze CS-117C Sunlight Readable Panel PC
SKU:IND-949346
Advanced 17" Sunlight Readable Panel PC for industrial environments; Intel Core i5, DDR5 support, high brightness display, rugged design.
Regular price
$1,899.99
Regular price
Sale price
$1,899.99
Unit price
per
Initiate Order
Cincoze CS-117C Sunlight Readable Panel PC
$1,899.99
Quantity: 1
Claim Your Seller Account
Cincoze CS-117C Sunlight Readable Panel PC
$1,899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Cincoze CS-117C Sunlight Readable Panel PC is a powerful and versatile industrial computing solution designed for outdoor and challenging environments. Featuring a 17" TFT-LCD display with a high brightness of 1500 nits and a durable modular design, this panel PC is equipped with an Intel 12th Gen Core i5-1245UE processor, dual DDR5 memory support up to 64GB, and integrated Intel Iris Xe graphics for exceptional computing performance. With a wide operating temperature range, IP65 front panel protection, and a variety of display options, the CS-117C ensures reliability, safety, and flexibility across various applications.
Product Specifications
Additional Information Additional Information
Excellent Computing PerformanceThe CS-100/P2202 series is equipped with the 12th Gen Intel® Core⢠i5/i3 U-series (Alder Lake-P) processor based on the Intel® 7 process. The U-series has a low power consumption of only 15W, boasts excellent performance with up to 10 Coreâ¢s (2P+8E), and includes the built-in Intel® Iris® Xe graphics to easily handle image classification inference performance in AI deep learning.CDS Patented TechnologyCincoze® Convertible Display System (CDS) patented technology makes field-side maintenance and future upgrades easier. Replacing a display or improving system performance only requires replacing a single component, which significantly cuts upgrade costs.Patent No. M482908Complete Range of SizesThe CS-100/P2202 series offers a variety of display options, with screen sizes from 12 to 24 inches, support for up to full HD resolution, high brightness up to 1,800 nits, and multi-point P-Cap touchscreen, which can be selected according to application needs.Wide Temps, Safe, ReliableIn order to overcome the harsh outdoor environment and unpredictable climate, the CS-100/P2202 series has a series of industrial-grade protections, including a wide operating temperature range (-20°C to 70°C) that beats the industry standard and an IP65 dustproof/water resistant front panel to ensure a high degree of product safety.
Audio Audio Codec
Realtek® ALC888, High Definition Audio
Audio Line Out
1x Line-Out, Phone Jack 3.5 mm
Audio Mic In
1x Mic-in, Phone Jack 3.5 mm
Cs 117 Backlight Mean Time Between Failures Mtbf Cs 117
50,000 h
Cs 117 Brightness Cs 117
1500 cd/m²
Cs 117 Contrast Ratio Cs 117
800:1
Cs 117 Depth Cs 117
350 mm
Cs 117 Electromagnetic Compatibility Emc Cs 117
European Conformity (CE) | Federal Communications Commission (FCC) | Interference-Causing Equipment Standard 003 (ICES-003 Class A) | United Kingdom Conformity Assessed (UKCA)
Cs 117 Electromagnetic Interference Emi Cs 117
CISPR 32 Conducted & Radiated: Class AEN/BS EN 55032 Conducted & Radiated: Class AEN/BS EN IEC 61000-3-2 Harmonic current emissions: Class AEN/BS EN61000-3-3 Voltage fluctuations & flickerFCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
Cs 117 Environmental Management System Ems Cs 117
EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kVEN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/mEN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kVEN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kVEN/IEC 61000-4-6 CS: 3VEN/IEC 61000-4-8 PFMF: 50 Hz, 1A/mEN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz
Cs 117 Front Panel Protection Cs 117
IP 65 Compliant
Cs 117 Height Cs 117
63.2 mm
Cs 117 Liquid Crystal Display Lcd Color Cs 117
16.7M
Cs 117 Liquid Crystal Display Lcd Size Cs 117
17 in | 5:4
Cs 117 Maximum Resolution Cs 117
1280 x 1024 (SXGA)
Cs 117 Mechanical Construction Cs 117
Flat Rugged Aluminum Die-Casting Bezel
Cs 117 Non Condensing Relative Humidity Rh At 40 Degree Celsius
90 %
Cs 117 Note For Ambient Operating Temperature With Air Flow Cs 1
With Industrial Grade Peripherals
Cs 117 Operating Temperature Cs 117
-20 to 80 ºC
Cs 117 Pixel Pitch Horizontal Cs 117
0.264 mm
Cs 117 Pixel Pitch Vertical Cs 117
0.264 mm
Cs 117 Safety Cs 117
Canadian Underwriters Laboratories (cUL) | Certification Body (CB) | European Norm (EN 62368-1) | International Electrotechnical Commission (IEC) | Underwriters Laboratories (UL)
Cs 117 Storage Temperature Cs 117
-30 to 80 ºC
Cs 117 Touchscreen Type Cs 117
Projected Capacitive
Cs 117 Viewing Angle Horizontal Vertical H V Cs 117
160/140
Cs 117 Weight Cs 117
5.64 kg
Cs 117 Width Cs 117
450 mm
Environment Electromagnetic Compatibility Emc
CE, UKCA, FCC, ICES-003 Class AEN IEC 61000-6-4, EN IEC 61000-6-2 (24VDC Input Only)
Environment Electromagnetic Interference Emi
CISPR 32 Conducted & Radiated: Class AEN/BS EN 55032 Conducted & Radiated: Class AEN/BS EN IEC 61000-3-2 Harmonic current emissions: Class AEN/BS EN61000-3-3 Voltage fluctuations & flickerFCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
Environment Environmental Management System Ems
EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kVEN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 10 V/mEN/IEC 61000-4-4 EFT: AC Power: 2 kV; DC Power: 1 kV; Signal: 1 kVEN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kVEN/IEC 61000-4-6 CS: 10VEN/IEC 61000-4-8 PFMF: 50 Hz, 30A/mEN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 1 cycles at 60 Hz
Physical Depth
190 mm
Physical Height
41.5 mm
Physical Width
254.5 mm
Power Power Button
1x ATX Power On/Off Button
Power Power Input
9 to 48 VDC, 3-Pin Terminal Block
Power Power Mode Switch
1x AT/ATX Mode Switch
Power Remote Power Onoff
1x Remote Power On/Off, 2-pin Terminal Block
Reliability And Protection Over Voltage Protection
Protection Range: 51~58VProtection Type: shut down operating voltage, re-power on at the present level to recover
Reliability And Protection Reverse Power Input Protection
Yes
