Class-2 Power Control Transformers - Safety-Approved for Institutional Applications
Class-2 Power Control Transformers - Safety-Approved for Institutional Applications
SKU:POW-472665
Enhance institutional electrical systems with safety-approved Class-2 Power Control Transformers. UL and cUL certified for reliability. Ideal for HVAC, control boards, lighting, and more.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Class-2 Power Control Transformers - Safety-Approved for Institutional Applications
$59.99
Quantity: 1
Claim Your Seller Account
Class-2 Power Control Transformers - Safety-Approved for Institutional Applications
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your institutional electrical systems with our Class-2 Power Control Transformers featuring tamper-resistant shrouds for safety and an easy-to-mount steel bracket. With UL and cUL certifications, these transformers meet Class 2 safety standards and offer reliable performance for HVAC, control boards, lighting, and more. Designed for efficiency and safety, these transformers ensure optimal voltage regulation and low temperature rise, complying with RoHS standards for environmentally friendly operation.
Product Specifications
Specifications Agency File
UL: File E65390, UL 5085-3 (1585), Class 2 TransformercUL: File E65390, UL 5085-3 (1585) For Canadian Use (CSA 22.2, No.66.3-06)
Specifications Connections
Input: Quick Disconnect tabs, 0.5 x 0.25 x 0.032 | Output: Quick Disconnect tabs, 0.5 x 0.187 x 0.032
Specifications Construction
Three flange bobbin construction with primaries and secondaries wound side by side for low capacitive coupling.
Specifications Hipot
1500 VAC - Input to Output, Input and Output to Core
Specifications Inherently Limited
No Fusing Required.
Specifications Input Frequency
50 Hz | 60 Hz
Specifications Maximum Power
40 V·A
Specifications Primary Input Voltage
120 V
Specifications Rohs Compliance
As of manufacturing date February 2016, all standard products meet the requirements of 2015/863/EU, known as the RoHS 3 initiative.
Specifications Secondary Output Voltage
24 V
Specifications Temperature Rise
<40 ºC
Specifications Voltage Regulation From Full Load To No L
15 %
Specifications Weight
1.50 lb
