Class 8.8 Steel Plain DIN 961 Metric Fine and Full Thread Hex Head Cap Screw Bolt

Name: Class 8.8 Steel Plain DIN 961 Metric Fine and Full Thread Hex Head Cap Screw Bolt
Brand: Aspen Fasteners
SKU: BOL-5846b6
Price: 49.99 USD
Availability: OutOfStock

SKU:BOL-5846b6

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Hex Bolts have a six-sided hexagonally shaped head designed to be mated with a nut. Conversely, Cap Screws are designed to be threaded into a pre-tapped hole, for example a piece of machinery. Cap Screws are typically produced to tighter tolerances than bolts and will feature a washer face under the head and a chamfered point.

Product Specifications

Additional Information

Hex cap screws are manufactured to tighter tolerances as compared to hex bolts.Class 8.8 steel is a tempered medium carbon steel with a minimum tensile strength of 800/mm-2 (Mpa).Washer face provides a precision bearing surface.Chamfered point improves engagement with a nut or pre-tapped hole.In general, fine thread fasteners are about 10% stronger than coarse threads under static loading.

Specifications Coating

Uncoated

Specifications Drive Style

External Hex Drive

Specifications Head Detail

Washer Face

Specifications Head Style

Hex Head

Specifications Industry Standards And Specifications

German Institute for Standardization (DIN 961)

Specifications Material

Steel

Specifications Material Grade

Class 8.8 Steel

Specifications Point

Chamfered Point

Specifications System Of Measurement

Metric

Specifications Thread Direction

Right-Hand Thread

Specifications Thread Length

Full Thread

Specifications Thread Pitch

Fine Thread
