Clear Silicone Flange Cap - 0.181" ID, 0.323" OD, 0.591" Flange

Name: Clear Silicone Flange Cap - 0.181" ID, 0.323" OD, 0.591" Flange
Brand: Custom Fabricating & Supplies
SKU: SIL-611e5c
Price: 45.99 USD
Availability: OutOfStock

SKU:SIL-611e5c

High-temp silicone cap for masking studs, Pems in finishing processes. Flexible, reusable, color-coded. 500-Pack.

$45.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The FC181-0591 Clear Silicone Flange Cap is a high-quality solution for masking studs and Pems in various finishing processes like powder coating, E-coating, wet painting, anodizing, and plating. With a temperature rating of 600°F/315°C, this cap offers superior heat resistance. Its flexible material allows it to conform to irregular shapes, ensuring a secure fit. The rounded top and color-coding for easy identification make it a versatile and reusable choice for industrial applications.

Product Specifications

Specifications Color

Clear

Specifications Features

Temperature Rating 600 Â°F/315 Â°C Recommended for Masking Studs and Pems with a Perimeter for Grounding Flexible Material Allows Cap to Conform to Irregular Shapes May be Inverted as a Plug Top of Cap is Rounded, not Flat Color Coded for Easy Identification and Reusable Used in Powder Coating, E-Coating, Wet Painting, Anodizing and Plating

Specifications Flange

0.591 Inch | 15.01 mm

Specifications Inner Diameter Id

0.181 Inch | 4.60 mm

Specifications Length

1.000 Inch | 25.40 mm

Specifications Outer Diameter Od

0.323 Inch | 8.20 mm

Specifications Quantitybag

500

Clear Silicone Flange Cap - 0.181" ID, 0.323" OD, 0.591" Flange
