The Clemco 4 Cu Ft Contractor Blast Machine is a field-portable, high-production blast pot rated at 150 psi for one operator. This single-chamber machine holds 4 cubic feet of blast media and features Millennium pneumatic remote controls and a Quantum manual metering valve. With a robust design and weather-resistant storage, this blast machine offers durability, ease of use, and precise control for efficient blasting operations. Meeting ASME codes and OSHA regulations, it ensures safety, compliance, and superior performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Advantages 0
Rated for 1 50-psi maximum working pressure1 1/2-inch Millennium valve provides unrestricted air flowQuantum metering valve maintains smooth , consistent flow, adjustment knob allows precise control of media flow1 1/4-inch piping allows up to 50 percent increase in air flow; when compared to 1-inch piping29-inch width fits through standard doorwaysFour-wheel integral cart for ease of movingRobust handles act as skid for loading machine into pickup or trailer and protect valves and piping from damage.Central hookup point for blast hose and remote controlsWeather-resistant storage area holds manuals, paperwork and small parts
Approvals And Certifications 0
Blast machine pressure vessel built to American Society of Mechanical Engineers (ASME) code for 150-psi working pressure . Vessel is hydrostatically tested and National Board certified. Remote control system complies with OSHA regulation 1910.244 (b).
Details 0
Purpose:High- performance blast cleaning system removes corrosion, mill scale, and coatings from most surfaces . Produces a uniform surface texture , and creates a surface profile to increase bonding for coatings. See related literature for additional applications. Machine holds 4 cubic feet of abrasive for up to 30 minutes of continuous blasting at 100 psi with standard No. 5 nozzle (5/16-inch orifice).Requirements for Operation:These items are required but not included with this equipment.Clean, dry, compressed air of sufficient volume to maintain desired pressure at the nozzle . See Air Consumption Chart in Blast Off 2 booklet.Maximum working pressure 150 psiMinimum pressure 30 psi needed to operate OSHA- required remote control valvesNIOSH-approved supplied-air respirator Grade D breathing- air supply as defined by the Compressed Gas Association Commodity Specification: G-7.1Abrasive blast media - consult abrasive supplier for appropriate media for your applicationBlast suit and work bootsDescription of Operation:The operator controls blasting from a remote control handle at the nozzle. Pressing the handle starts blasting, releasing it stops blasting. The blast machine contains abrasive and meters it into the compressed air stream.Note:For safe, efficient blasting, read and follow the owner's manual and seek training for everyone who will use this equipment.
Specifications Color
Champagne
Specifications Floor To Center Of Hose Coupling
3 5/8 in
Specifications Floor To Center Of Inlet Pipe
27 3/8 in
Specifications Height Floor To Highest Point
49 in
Specifications Height Floor To Highest Point Including Skid
54 in
Specifications Length Hose Coupling To Handle
47 3/4 in
Specifications Length Hose Coupling To Handle Including Skid
48 in
Specifications Machine Diameter
20 in
Specifications Net Weight
382 lbs
Specifications Outside Handles Width
20 1/8 in
Specifications Packaging
Secured on skid and shrink wrapped
Specifications Part
Contractor blast machine
Specifications Pressure
150 psi
Specifications Shipping Volume
52.5 ft³
Specifications Shipping Weight
454 lbs
Specifications Width Outside Hub To Hub
29 in
Specifications Width Outside Hub To Hub Including Skid
35 in
