Clip-On Fixed Jaw for Cable Railing
Clip-On Fixed Jaw for Cable Railing
SKU:ARC-d37f1a
Secure and hassle-free cable attachment with Clip-On Fixed Jaw for easy railing installations.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Clip-On Fixed Jaw for Cable Railing
$24.99
Quantity: 1
Claim Your Seller Account
Clip-On Fixed Jaw for Cable Railing
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Clip-On Fixed Jaw is a specialized end fitting for architectural cable railings, designed for easy cable attachment with a special clip that eliminates the need for field swaging. This Fixed Jaw is compatible with Invisiware® receivers or Adjust-A-Jaw® tensioners, ensuring secure and hassle-free installation. All hardware comes pre-swaged at the factory, available for 1/8" and 3/16" cables. Streamline your railing projects with this efficient and durable end fitting.
Product Specifications
Specifications D Dia
0.260 "
Specifications E Thread
1/4-28
Specifications G
0.260 "
Specifications K
0.56 "
Specifications L
1.75 "
Specifications Use With Ferrule No
F-6
Specifications Use With Screw No
SC-6
Specifications Wire Rope Dia
3/16 "
CAGE
0T9L4
NAICS
332999
PSC
5340
