Co-Cr-W Forged Cobalt 6B Alloy
Co-Cr-W Forged Cobalt 6B Alloy
SKU:COB-2a3dc2
High-performance Co-Cr-W forged alloy offering exceptional durability and reliability in extreme conditions.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Co-Cr-W Forged Cobalt 6B Alloy
$99.99
Quantity: 1
Claim Your Seller Account
Co-Cr-W Forged Cobalt 6B Alloy
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience exceptional durability and hot strength retention with our Co-Cr-W Forged Cobalt 6B Alloy. Ideal for replacing castings due to enhanced ductility and reliability for sealing surfaces. Minimize seizing, galling, and wear without lubrication. Perfect for turbine engine components, steam turbines, pump applications, and more.
Product Specifications
Additional Information Additional Information
Cobalt 6B is cobalt based chromium, tungsten alloy for wear environments where seizing, galling and abrasion are present. 6B is resistant to seizing and galling and with its low coefficient of friction, allows sliding contact with other metals without damage by metal pick up in many cases. Seizing and galling can be minimized in applications without lubrication or where lubrication is impractical. Metal seizing is similar to one metal piece building heat against another and they become "welded" together. Galling is when these "weld" areas break off and form abrasive debris which creates additional abrasion problems.Alloy 6B has outstanding resistance to most types of wear. Its wear resistance is inherent and not the result of cold working, heat treating or any other method. This inherent property reduces the amount of heat treating and post machining. 6B has outstanding resistance to cavitation erosion. Steam turbine erosion shields from 6B have protected the blades of turbines for years of continuous service. 6B has good impact and thermal shock resistance resists heat and oxidation, retains high hardness even at red heat (then cooled, recovers full original hardness) and has resistance to a variety of corrosive media. 6B is useful where both wear and corrosion resistance is needed.
Applications 0
Steam turbine erosion shields, Chain saw guide bars, High temperature bearings, Furnace fan blades, Valve stems, Food processing equipment, Needle valves, Centrifuge liners, Hot extrusion dies, Forming dies, Nozzles, Extruder screws & many other Misc. wear surfaces.Applications for alloy 6B include half sleeves and half bushings in screw conveyors, tile making machines, rock crushing rollers and cement and steel mill equipment. Alloy 6B is well suited for valve parts, pump plungers.Wrought alloy 6B offers the ductility, fatigue resistance and toughness of a hot worked microstructure, with the heat corrosion and wear resistance of cobalt based alloy. High Performance Alloys, Inc. inventories bar, sheet, and plate. Bar is stocked from 3/8" through 6" diameter. Bar can be supplied in random lengths or cut to order. Sheet and plate are offered as whole plates, can be abrasive cut, or processed further using water jet services.
General Resistance Barrod Usa
AMS 5894
General Resistance Fitting Usa
NA
General Resistance Forging Usa
AMS 5894
General Resistance General Resistance
Temperature | Oxidation | Wear | Galling
General Resistance Sheetplate Usa
AMS 5894
General Resistance Unified Numbering System Uns
R30016
Mechanical Elongation
7 to 12 %
Mechanical Hardness
C33 - 43
Mechanical Mechanical Type
Annealed
Mechanical Tensile Strength
145 ksi
Mechanical Yield Strength
90 ksi
Nominal Chemistry Carbon C
1
Nominal Chemistry Chromium Cr
30
Nominal Chemistry Cobalt Co
59
Nominal Chemistry Iron Fe
Balanced
Nominal Chemistry Manganese Mn
1.4
Nominal Chemistry Nickel Ni
2.5
Nominal Chemistry Tungsten W
3.5
Physical Density
0.330 lb/in³
Physical Electrical Resistivity
574 ohm/cir-mil-ft
Physical Melting Range
2310 to 2470 ºF
Physical Specific Heat
0.100 Btu/lb ºF
Physical Thermal Expansion Coefficient At 32 To 390 Degree Fahre
7.8 x 10-6 in/in/ºF
Specifications Alloy
6B
Specifications Process
Forged
