Co66/Si15/B 14/Fe 4/Ni 1 Foil - 0.025mm Thickness
Co66/Si15/B 14/Fe 4/Ni 1 Foil - 0.025mm Thickness
SKU:COB-c22721
High-performance Co66/Si15/B 14/Fe 4/Ni 1 Foil - 0.025mm thickness, ideal for diverse applications. Superior strength, exceptional electrical and magnetic properties.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Co66/Si15/B 14/Fe 4/Ni 1 Foil - 0.025mm Thickness
$39.99
Quantity: 1
Claim Your Seller Account
Co66/Si15/B 14/Fe 4/Ni 1 Foil - 0.025mm Thickness
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Co66/Si15/B 14/Fe 4/Ni 1 Foil with a thickness of 0.025mm offers exceptional strength and flexibility. This metallic glass foil boasts high electrical resistivity, superior mechanical properties including a Vickers hardness of 960 Kgf mm-2, and a tensile modulus of 61.00 GPa. Its magnetic properties include a Coercivity of 0.24 A m-1 and a Curie Temperature of 205°C, making it ideal for various applications. With a density of 7.590 g·cm-3 and a maximum use temperature in air of 80°C, this foil provides reliability and performance in demanding environments. Suitable for soft magnetic applications, brazing, coating, and as reinforcing fibers.
Product Specifications
Electrical Properties Electrical Resistivity
142 µΩ·cm
Magnetic Properties Coercivity As Cast
0.24 A m-1
Magnetic Properties Curie Temperature
205 ºC
Magnetic Properties Remanence Ratio Brbs
0.82
Magnetic Properties Saturation Flux Density
0.55 T
Magnetic Properties Saturation Magnetostriction
< 1 x10-6
Mechanical Properties Hardness Vickers
960 Kgf mm-2
Mechanical Properties Tensile Modulus
61.00 GPa
Mechanical Properties Tensile Strength
> 700.00 MPa
Note Note
Metallic glasses (glassy alloys) or amorphous metals. Uses include soft magnetic applications, brazing, coating and as reinforcing fibres.
Physical Properties Density
7.590 g·cm-3
Specifications Coil Width
25 mm
Specifications Form
Foil
Specifications Grade
Metallic Glass
Specifications Thickness
0.025 mm
Thermal Properties Crystallization Temperature
550 ºC
Thermal Properties Maximum Use Temperature In Air
80 ºC
Tolerances Tolerance For 001 Millimeter Mm Thickness
25 %
Tolerances Tolerance For 005 Millimeter Mm Thickness
10 %
Tolerances Tolerance For 100 Millimeter Mm Coil Length
+1 % | +2 %
Tolerances Tolerance For 100 Millimeter Mm Disc Diameter
+1 % | +2 %
Tolerances Tolerance For 100 Millimeter Mm Length 1 Light Tight
+1 % | +2 %
Tolerances Tolerance For 100 Millimeter Mm Length 2 Light Tight
+1 % | +2 %
Type Type
GlassGoodfellow offers two distinct types of glass products: The first are generally silica-based, non-crystalline (amorphous) solids which exhibit a glass transition and are brittle and transparent. The properties of glass materials can be readily modified to alter their optical performance and other characteristics. This type is available through Goodfellow's Ceramic and Glass Division. Generally, these products are made to order for customers, so we do not list them in our Catalogue. Please contact us with your requirements. The second type of glass product is commonly referred to as "metallic glasses" or "glassy metals". In contrast to crystalline metals and alloys with highly ordered atomic structures, these are non-crystalline (amorphous) metals or, more usually, alloys. Our website details those glassy metals which are available from stock; please contact us if you are unable to find the item you specifically require.
