Experience the compact power of our Chassis Mount Quick Pack™ Power Transformers, designed to maximize efficiency with reduced size and weight without compromising performance. The bobbin-wound construction and split bobbin nonconcentric winding eliminate the need for costly electrostatic shielding, making these transformers ideal for a wide range of applications. With an electrical rating of 30.0 VA and Class B insulation for a maximum temperature of 130 °C, these transformers ensure reliable operation and easy termination for quick connects or soldering.
Product Specifications
Specifications Dimension A
2 5/16 in
Specifications Dimension B
1 1/16 in
Specifications Electrical Rating
30.0 V·A
Specifications Height H
1 15/16 in
Specifications Length L
3 1/4 in
Specifications Mounting Hole Size
3/16 in
Specifications Mounting Length
2 13/16 in
Specifications Output Rating
16.0 V CT at 2.0 A
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V
Specifications Transformer Contact Type
Center Tap
Specifications Type
Single Primary
Specifications Weight
1.10 lb
Specifications Width W
1 11/16 in
Technical Notes 0
Hi-pot tested at 2,500 VRMS.Class B insulation for maximum temperature of 130 ºC.Terminal size is 0.187" x 0.021".
