The Chassis Mount Quick Pack™ Power Transformers from Triad offer a compact and lightweight solution with a reduced size and weight compared to traditional transformers. This series, available in six sizes, is perfect for various applications. Featuring bobbin wound design for space efficiency and split bobbin nonconcentric winding for cost savings, these transformers deliver reliable performance. Suitable for quick connects or soldering, these transformers are hi-pot tested, Class B insulated for up to 130ºC, and feature a center tap configuration. Overall, they combine efficiency with space-saving benefits for optimized power distribution.
Product Specifications
Specifications Dimension A
1 11/16 in
Specifications Dimension B
11/16 in
Specifications Electrical Rating
6.0 V·A
Specifications Height H
1 3/8 in
Specifications Length L
2 3/8 in
Specifications Mounting Hole Size
3/16 in
Specifications Mounting Length
2 in
Specifications Output Rating
56.0 V CT at 0.11 A
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V
Specifications Transformer Contact Type
Center Tap
Specifications Type
Single Primary
Specifications Weight
0.40 lb
Specifications Width W
1 1/4 in
Technical Notes 0
Hi-pot tested at 2,500 VRMS.Class B insulation for maximum temperature of 130 ºC.Terminal size is 0.187" x 0.021".
