Compact Power Transformers - Quick Pack⢠Series
Compact Power Transformers - Quick Pack⢠Series
SKU:POW-199ce6
Optimize your power systems with Triad Quick Pack⢠Power Transformers - compact, efficient, and reliable.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Compact Power Transformers - Quick Pack⢠Series
$24.99
Quantity: 1
Claim Your Seller Account
Compact Power Transformers - Quick Pack⢠Series
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your power system efficiency with Triad Quick Pack⢠small power transformers. Designed for optimal size and weight reduction without compromising performance. Bobbin wound for compactness and space-saving. With split bobbin nonconcentric winding, eliminate the need for costly electrostatic shielding. Suitable for quick connects or soldering, these transformers offer reliable and efficient power distribution.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Dimension A
1 5/8 in
Specifications Dimension B
9/16 in
Specifications Electrical Rating
2.4 V·A
Specifications Height H
1 3/16 in
Specifications Length L
2 1/16 in
Specifications Mounting Hole Size
3/16 in
Specifications Mounting Length
1 3/4 in
Specifications Output Rating
36.0 V CT at 0.065 A
Specifications Primary Frequency
50 Hz | 60 Hz
Specifications Primary Voltage
115 V
Specifications Transformer Contact Type
Center Tap
Specifications Type
Single Primary
Specifications Weight
0.30 lb
Specifications Width W
1 3/16 in
Technical Notes 0
Hi-pot tested at 2,500 VRMS.Class B insulation for maximum temperature of 130 ºC.Terminal size is 0.187" x 0.021".
