Compact Turn-Act 32 in·lb Rotary Vane Actuator
Compact Turn-Act 32 in·lb Rotary Vane Actuator
SKU:ROT-160f43
High-torque rotary vane actuator for accurate positioning in industrial applications.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
Compact Turn-Act 32 in·lb Rotary Vane Actuator
$299.99
Quantity: 1
Claim Your Seller Account
Compact Turn-Act 32 in·lb Rotary Vane Actuator
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Compact Turn-Act 32 in·lb Rotary Vane Actuator features a 180º rotation angle and precise unidirectional clutch for accurate and repeatable positioning. This pneumatic actuator, suitable for various applications like turntable workstations and conveyor drive systems, offers customizable options for specialized needs. With a maximum torque of 32 in·lb and reliable aluminum construction, it meets rigorous industry standards for durability and performance.
Product Specifications
Applications Include Applications Include
Turntable Work StationsDrive Conveyor Rollers or BeltsDrive Material Feed RollersRatchet Type DriveSheet Feed Material From a StackPeristalsis Pump DriveLow Speed High Torque MotorProduct Mixing
Application Considerations Application Considerations
Overrun: The output shaft can be manually rotated only in its drive direction. Large loads may coast after the actuator has stopped. The output shaft cannot be reverse rotated- Forcing it backwards could damage the Turn-DeAccurate & Repeatable Positioning: Due to the overrun nature of the clutch eSpecial Options: Turn-Act will provide customized units to fit your specific application needs. Modifications include special shafting, special mounts, dutch housings with shot-pin cylinders, disc brakes and thrust protection. Consult your Compact distributor for additional information.
Features Features
Position Feedback (Optional)
Specifications Actuator Style
Rotary Vane (Single)
Specifications Body Material
Aluminum
Specifications Length
4.84 in
Specifications Maximum Torque
32 in·lb
Specifications Number Of Shafts
Single Shaft
Specifications Operating Pressure Range High
200 psi
Specifications Operating Pressure Range Low
35 psi
Specifications Operating Temperature High
180 ºF
Specifications Operating Temperature Low
-20 ºF
Specifications Physical Dimensions
1.62 in²
Specifications Rotational Output
Shaft
Specifications Rotation Angle
180 º
Specifications Shaft Length Or Table Height
1 in
Specifications Shaft Or Table Diameter
0.625 in
Specifications Standard
english_1_1_4
Specifications Technology Type
Pneumatic
