Consolidated 18 AWG Bare Nickel Chromium Resistance Wire
Consolidated 18 AWG Bare Nickel Chromium Resistance Wire
SKU:UNI-a4845e
High-performance 18 AWG nickel chromium bare wire for antenna and satellite applications. Solid, durable, and reliable.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Consolidated 18 AWG Bare Nickel Chromium Resistance Wire
$29.99
Quantity: 1
Claim Your Seller Account
Consolidated 18 AWG Bare Nickel Chromium Resistance Wire
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Consolidated 18 American Wire Gauge (AWG) Wire is designed for high-performance applications, featuring a solid soft drawn composition of 80% Nickel and 20% Chromium. With a maximum operating temperature of 1148C (2100F) and a melting point of 1400C (2550F), this wire offers exceptional durability and reliability. It boasts a tensile strength of 100-120 KSI, a yield strength of 45-55 KSI, and 20% elongation for flexibility. Ideal for antenna lead wire and satellite applications, this wire ensures superior conductivity and resistance. Each foot provides precise element resistance and weighs .304 lbs/cubic inch. Available in 1/4 lb spools or larger quantities.
Product Specifications
Applications Applications
Suitable for antenna lead wire and satalite applications.
Note Note
All specifications are subjected to change without prior notice.
Technical Specs Brands
Consolidated Electronic Wire & Cable
Technical Specs Color Code
Custom Colors not available.
Technical Specs Material
Nickel
Technical Specs Nominal Outside Diameter Od
0.04 in
Technical Specs Packaging
Available on 1/4 lb spools or greater, minimum order quantity may applyAvailable on bulk reels
Technical Specs Stranding
Solid
Technical Specs Weight Per 1000 Feet Ft
4.65 lb
Technical Specs Wire Thickness
18 AWG
