Continuous Analyzer for Biogas Recovery & Processing - Methane + Carbon Dioxide
Continuous Analyzer for Biogas Recovery & Processing - Methane + Carbon Dioxide
SKU:BYS-a40eb7
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Continuous Analyzer for Biogas Recovery & Processing - Methane + Carbon Dioxide
$49.99
Quantity: 1
Claim Your Seller Account
Continuous Analyzer for Biogas Recovery & Processing - Methane + Carbon Dioxide
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Nova 920 Series analyzers have been designed for monitoring recovered and processed gases from biogas installations. The Model 924 is specifically designed for continuous carbon dioxide (CO2) and methane (CH4) measurement. The sample conditioning system continuously removes moisture from the wet sample gas without the need for cooling water, compressed air, or failure-prone thermoelectric elements. The 920 Series comes complete with pre-filter, sample pump, flow meter, continuous moisture removal system, infrared CO2 & HC's detector (as CH4), low flow sensor, alarm relay contacts, and 4-20mA output. Sensors / detectors are mounted in an internal dedicated enclosure which is temperature-controlled to reduce drift due to ambient temperature swings. The internal sensor enclosure is removable to allow quick field change of sensors. The infrared detector can be cleaned in the field if necessary by the on-site technician. Ranges:Carbon Dioxide: any range between 0-50.0% to 0-100.0% CO2Methane: any range between 0-50.0% to 0-100.0% HC's (as CH4) Models:924A with manual calibration924C with automatic calibration
Product Specifications
Specifications Ranges Available
Any range between 0-50.0% and 0-100.0% CH4, CO2
