Contractor Pressure Blast Pot - 2 Cu Ft
Contractor Pressure Blast Pot - 2 Cu Ft
SKU:CLE-2961e8
High-performance blast cleaning system with 150 psi pressure, 2 cu ft capacity, and ASME compliance.
Regular price
$2,799.99
Regular price
Sale price
$2,799.99
Unit price
per
Initiate Order
Contractor Pressure Blast Pot - 2 Cu Ft
$2,799.99
Quantity: 1
Claim Your Seller Account
Contractor Pressure Blast Pot - 2 Cu Ft
$2,799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Contractor Pressure Blast Pot is a high-performance blast cleaning system designed to remove corrosion, mill scale, and coatings from surfaces. With a 150 psi working pressure and a capacity of 2 cubic feet, this machine ensures efficient and uniform surface texture creation, enhancing bonding for coatings. Equipped with a Millennium valve, Quantum metering valve, and robust handles for easy maneuvering, it meets ASME standards, OSHA regulations, and NIOSH requirements for safe operation.
Product Specifications
Advantages 0
Rated for 1 50-psi maximum working pressure1 1/2-inch Millennium valve provides unrestricted air flowQuantum metering valve maintains smooth , consistent flow, adjustment knob allows precise control of media flow29-inch width fits through standard doorwaysTwo-wheel integral cart for ease of movingRobust handles act as skid for loading machine into pickup or trailer and protect valves and piping from damage.Central hookup point for blast hose and remote controlsWeather-resistant storage area holds manuals, paperwork and small parts
Approvals And Certifications 0
Blast machine pressure vessel built to American Society of Mechanical Engineers (ASME) code for 150-psi working pressure . Vessel is hydrostatically tested and National Board certified. Remote control system complies with OSHA regulation 1910.244 (b).
Details 0
Purpose:High- performance blast cleaning system removes corrosion, mill scale, and coatings from most surfaces . Produces a uniform surface texture , and creates a surface profile to increase bonding for coatings. See related literature for additional applications. Machine holds 2 cubic feet of abrasive for up to 30 minutes of continuous blasting at 100 psi with standard No. 4 nozzle (1/4-inch orifice).Requirements for Operation:These items are required but not included with this equipment.Clean, dry, compressed air of sufficient volume to maintain desired pressure at the nozzle . See Air Consumption Chart in Blast Off 2 booklet.Maximum working pressure 150 psiMinimum pressure 30 psi needed to operate OSHA- required remote control valvesNIOSH-approved supplied-air respirator Grade D breathing- air supply as defined by the Compressed Gas Association Commodity Specification: 6-7.1Abrasive blast media - consult abrasive supplier for appropriate media for your applicationBlast suit and work bootsDescription of Operation:The operator controls blasting from a remote control handle at the nozzle. Pressing the handle starts blasting, releasing it stops blasting. The blast machine contains abrasive and meters it into the compressed air stream.Note:For safe, efficient blasting, read and follow the owner's manual and seek training for everyone who will use this equipment.
Specifications Color
Champagne
Specifications Floor To Center Of Hose Coupling
3 1/4 in
Specifications Floor To Center Of Inlet Pipe
24 3/8 in
Specifications Height Floor To Highest Point
44 in
Specifications Height Floor To Highest Point Including Skid
49 in
Specifications Length Hose Coupling To Handle
39 in
Specifications Length Hose Coupling To Handle Including Skid
40 in
Specifications Machine Diameter
16 in
Specifications Net Weight
258 lbs
Specifications Outside Handles Width
19 1/4 in
Specifications Packaging
Secured on skid and shrink wrapped
Specifications Part
Contractor Blast Machine
Specifications Pressure
150 psi
Specifications Shipping Volume
39.7 ft³
Specifications Shipping Weight
326 lbs
Specifications Width Outside Hub To Hub
28 3/4 in
Specifications Width Outside Hub To Hub Including Skid
35 in
