Control Head Cable Assembly

Control Head Cable Assembly

SKU:PUS-a36596

Experience precision and durability with the Control Head Cable Assembly. Factory assembled, trim-to-length, stainless steel innermember. Up to 3" travel, 5" minimum bend radius.

Regular price $49.99
Regular price Sale price $49.99
Sale

Initiate Order

Control Head Cable Assembly

Control Head Cable Assembly

$49.99

Quantity: 1

Claim Your Seller Account

Control Head Cable Assembly

Control Head Cable Assembly

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Control Head Cable Assembly is meticulously crafted for precision performance in industrial applications. It features a factory-assembled design with a trim-to-length option, ensuring a perfect fit for diverse control needs. The stainless steel solid wire innermember guarantees durability and stability, while the up to 3" travel, 5" minimum bend radius, and a 20 lb pull load rating reflect its robust construction. Ideal for push-pull controls, this assembly offers reliability and efficiency in demanding environments.

Product Specifications

Specifications Cable Travel
1 " | 2 " | 3 "
Specifications Conduit Size
Light Duty
Specifications Conduit Type
Low Friction-EXT
Specifications Control Head Type
Non-Locking with 7/16-20 UNF Mounting
Specifications Knob Option
013 | 018 | 203
Specifications Output End Fittings
2 - Threaded Twist On | 3 - Grooved Twist On | 4 - Threaded Swaged | 5 - Grooved Swaged | 6 - Closed End Swaged
Specifications Seal Options
5 - Improved Model 5 Wiper Seal is Standard on Low Friction - EXT & Utility | 6 - Model 6 Wiper Seal, Optional on All Controls
Specifications Stainless Steel Options
Carbon Steel Fittings
CAGE
0T9L4
NAICS
332510
PSC
4030
