Enhance your workflow with our Coreless Log Saw, ensuring precision cuts for 4-6" diameter logs with ease and efficiency.
Regular price
$15,999.00
Regular price
Sale price
$15,999.00
Unit price
per
Initiate Order
Coreless Log Saw - Dual-Lane Compact Design
$15,999.00
Quantity: 1
Claim Your Seller Account
Coreless Log Saw - Dual-Lane Compact Design
$15,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Coreless Log Saw is an innovative solution designed to seamlessly integrate with coreless rewinders, ensuring precise cuts for logs ranging from 4" to 6" in diameter. Featuring a single-head, dual-lane configuration, this saw offers exceptional productivity of up to 60 clips per minute. With a clamping range that provides ±0.188" diameter tolerance, it guarantees high-quality cuts consistently. Additionally, the optional Grinding Dust Removal System with Wet Scrubber enhances operational efficiency. Ideal for industries requiring reliable and efficient cutting solutions.
Product Specifications
Specifications Clamping Range
±0.188" | 4.7 mm Product Diameter Tolerance (within Log Diameter Range) | 13 to 25 mm
Specifications Clip Length Range
3.5" to 12" | 89 to 305 mm
Specifications Core Diameter Range
0.5" to 1"
Specifications Density
0 to 22 lb/ft³ | 0 to 352 kg/m³
Specifications Grinding Dust Removal
Optional System with Wet Scrubber
Specifications Log Diameter Range
4" to 6" | 102 to 152 mm
Specifications Log Length
80" to 105" | 2032 to 2667 mm
Specifications Maximum Blade Diameter
24" | 607 mm
Specifications Minimum Blade Diameter
20" | 508 mm
Specifications Productivity
Up to 60 clips/min
