CPVC High Temperature Round Bar
CPVC High Temperature Round Bar
SKU:SHA-55a165
High heat-resistant CPVC Round Bar for elevated temperature applications, meeting ASTM D1784 & UL94 V0 standards.
Regular price
$35.99
Regular price
Sale price
$35.99
Unit price
per
Initiate Order
CPVC High Temperature Round Bar
$35.99
Quantity: 1
Claim Your Seller Account
CPVC High Temperature Round Bar
$35.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CPVC High Temperature Round Bar is a specialized chlorinated polyvinyl chloride material designed for high heat and corrosion resistance applications. With a maximum service temperature of 217°F, this CPVC rod offers exceptional dimensional stability, excellent chemical resistance, and low moisture absorption. Ideal for self-supporting constructions in elevated temperature environments, it meets ASTM D1784 Class 23447-B and UL94 V0 standards. Its physical properties include a specific gravity of 1.55 gm/cc, tensile strength of 8000 psi, flexural strength of 15100 psi, and a heat deflection temperature of 217°F.
Product Specifications
Specifications Dielectric Strength Astm D149
1250 V/mil
Specifications Flame Spread E84
15
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus
415000 psi
Specifications Flexural Strength
15100 psi
Specifications Hardness Rockwell Astm D785
R119
Specifications Heat Deflection Temperature At 264 Psi
217 ºF
Specifications Izod Impact Strength Astm D256
1.5 ft·lb/in
Specifications Limiting Oxygen Index Astm D2863
60 %
Specifications Specific Gravity Astm D792
1.55 gm/cc
Specifications Standard Length
10 ft | 4 ft | 8 ft
Specifications Tensile Strength Astm D638
8000 psi
Specifications Tolerance
+ 0.015 in | - 0.00 in
Specifications Water Absorption 24 Hrs 73f Astm D570
0.03 %
Specifications Weight
2.384 lb/ft
