CV24 Series 1 in High Flow Control Valve with 60° Angle Rigid Tip
CV24 Series 1 in High Flow Control Valve with 60° Angle Rigid Tip
SKU:SAM-0b6134
Enhance fluid dispensing with the CV24 Series 1 in High Flow Control Valve featuring a 60° angle rigid tip. Ideal for fleet service and lube trucks.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
CV24 Series 1 in High Flow Control Valve with 60° Angle Rigid Tip
$349.99
Quantity: 1
Claim Your Seller Account
CV24 Series 1 in High Flow Control Valve with 60° Angle Rigid Tip
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CV24 Series High Flow Control Valve is an essential component for dispensing large volumes of lubricants and antifreeze solutions. Built to handle demanding applications in fleet service, lube trucks, mining, construction, and more, this valve features a maximum free flow rate of 24 gpm and a maximum working pressure of 1,450 psi. With a 1-inch turn size and a 60-degree angle rigid semi-automatic no-drip tip, it ensures precise and efficient fluid handling. The valve is constructed with durable materials like aluminum, NBR, zinc-plated steel, and brass, making it reliable for handling various fluids including antifreeze solutions, ATF, gear oil, hydraulic fluids, synthetic and mineral-based oils.
Product Specifications
Application Application
Fleet Service | Lube Trucks | Mining and Construction | Railroad and Mass Transit Vehicles | Truck Dealerships
Specifications Angle
60 º
Specifications Fluid Handled
Antifreeze Solutions | Automatic Transmission Fluid (ATF) | Gear Oil | Hydraulic Oil and Fluids | Synthetic and Mineral Based Oil
Specifications Fluid Inlet Thread Size
3/4 in | 1 in
Specifications Fluid Inlet Thread Type
National Pipe Taper Fuel (NPTF)
Specifications Fluid Outlet Thread Size
3/4 in
Specifications Fluid Outlet Thread Type
British Standard Pipe Fitting (BSPF)
Specifications Maximum Free Flow Rate
24 gpm | 90 L/min
Specifications Maximum Working Pressure
1,450 psi | 100 bar
Specifications Turn Size
1 in
Specifications Wetted Materials
Aluminum | Nitrile Butadiene Rubber (NBR) | Zinc Plated Steel and Brass
