CVP Double Pole Single Throw (DPST) On-On Toggle Switch
CVP Double Pole Single Throw (DPST) On-On Toggle Switch
SKU:CVP-5315a4
Reliable CVP DPST On-On Toggle Switch for various applications. Durable construction with nickel-plated brass handle and silver contacts.
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
CVP Double Pole Single Throw (DPST) On-On Toggle Switch
$12.99
Quantity: 1
Claim Your Seller Account
CVP Double Pole Single Throw (DPST) On-On Toggle Switch
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CVP Double Pole Single Throw (DPST) On-On Toggle Switch is a versatile choice for various applications. Featuring a durable nickel-plated brass handle and silver contacts, this toggle switch ensures reliable performance. The phenolic housing with plated steel cap, along with nickel-plated brass mounting hardware, enhances durability. With a 15/32-32 thread mounting stem and 4 blade terminals for easy connections, this switch is rated for 25A at 12V, 15A at 24V, and 10A at 36V DC. Its DPST On-Off function provides clear operation - Up for On and Down for Off.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Accessories Accessories
Item # - 81264Item Name - Accessories for Toggle SwitchesDescription - Countersunk faceplate switch guards. Surface mount switch guard. Lockout switch guard cover. Emergency marine cutoff lanyards.Housing - Silicone RubberItem # - 81264-01Item Name - Accessories for Toggle SwitchesDescription - Countersunk faceplate switch guards. Surface mount switch guard. Lockout switch guard cover. Emergency marine cutoff lanyards.Housing - Silicone Rubber
Specifications Cap Material
Plated Steel
Specifications Contact Material
Silver
Specifications Current At 12 Volt V Voltage
25 A
Specifications Current At 24 Volt V Voltage
15 A
Specifications Current At 36 Volt V Voltage
10 A
Specifications Direct Current Dc Voltage
12 V | 24 V | 36 V
Specifications Handle Length
11/16 in | 17.5 mm
Specifications Handle Material
Nickel Plated Brass
Specifications Handle Type
Standard
Specifications Housing
Phenolic
Specifications Mounting Hardware
Nickel-Plated Brass
Specifications Mounting Stem Length
15/32 in | 11.9 mm
Specifications Mounting Stem Material
Nickel-Plated Brass
Specifications Mounting Stem Thread Size
15/32-32 in
Specifications Number Of Terminals
4
Specifications Panel Thickness
9/32 in | 7.1 mm
Specifications Terminal Type
Blade
Specifications Type
Double Pole Single Throw (DPST)
