The CVP Double Pole Double Throw (DPDT) Reversing Polarity Toggle Switch is a versatile forward-reverse switch designed for use with permanent magnet motors. It features a momentary On-Off-Momentary On functionality, with a standard length handle made of nickel-plated brass for durability. The switch has silver contacts for efficient electrical conductivity and a phenolic housing with a plated steel cap. With a mounting stem crafted from nickel-plated brass and blade terminals for quick-connectivity, this switch is designed to meet the needs of both consumer and institutional buyers. Rated for up to 25A at 12V, 15A at 24V, and 10A at 36V DC, this toggle switch is a reliable choice for various applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Accessories Accessories
Item # - 81264Item Name - Accessories for Toggle SwitchesDescription - Countersunk faceplate switch guards. Surface mount switch guard. Lockout switch guard cover. Emergency marine cutoff lanyards.Housing - Silicone RubberItem # - 81264-01Item Name - Accessories for Toggle SwitchesDescription - Countersunk faceplate switch guards. Surface mount switch guard. Lockout switch guard cover. Emergency marine cutoff lanyards.Housing - Silicone Rubber
Specifications Cap Material
Plated Steel
Specifications Contact Material
Silver
Specifications Current At 12 Volt V Voltage
25 A
Specifications Current At 24 Volt V Voltage
15 A
Specifications Current At 36 Volt V Voltage
10 A
Specifications Direct Current Dc Voltage
12 V | 24 V | 36 V
Specifications Handle Length
11/16 in | 17.5 mm
Specifications Handle Material
Nickel Plated Brass
Specifications Handle Type
Standard
Specifications Housing
Phenolic
Specifications Mounting Hardware
Nickel-Plated Brass
Specifications Mounting Stem Length
15/32 in | 11.9 mm
Specifications Mounting Stem Material
Nickel-Plated Brass
Specifications Mounting Stem Thread Size
15/32-32 in
Specifications Number Of Terminals
4
Specifications Panel Thickness
9/32 in | 7.1 mm
Specifications Terminal Type
Blade
Specifications Type
Double Pole Double Throw (DPDT)
