CVP Illuminated Toggle Switch - SPST On-Off
CVP Illuminated Toggle Switch - SPST On-Off
SKU:CVP-857353
CVP SPST Illuminated Toggle Switch for reliable and efficient operation with 25A at 12V DC. Designed for easy installation and clear functionality.
Regular price
$14.99
Regular price
Sale price
$14.99
Unit price
per
Initiate Order
CVP Illuminated Toggle Switch - SPST On-Off
$14.99
Quantity: 1
Claim Your Seller Account
CVP Illuminated Toggle Switch - SPST On-Off
$14.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CVP Single Pole Single Throw (SPST) On-Off Illuminated Toggle Switch features a clear plastic handle with a lighted design, ensuring easy visibility. With silver contacts for durability, this switch is designed for efficiency and reliability. The black nylon plastic mounting stem with 15/32-32 thread fits panels up to 1/8 inches thick. This switch handles 25A at 12V DC and comes with four 6-32 screw terminals. The red 'On' and white 'Off' markings provide clear identification. Plus, the O-ring seal in the bushing enhances protection, making it ideal for various applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Accessories Accessories
Item # - 81264Item Name - Accessories for Toggle SwitchesDescription - Countersunk faceplate switch guards. Surface mount switch guard. Lockout switch guard cover. Emergency marine cutoff lanyards.Housing - Silicone RubberItem # - 81264-01Item Name - Accessories for Toggle SwitchesDescription - Countersunk faceplate switch guards. Surface mount switch guard. Lockout switch guard cover. Emergency marine cutoff lanyards.Housing - Silicone Rubber
Specifications Contact Material
Silver
Specifications Current
25 A
Specifications Direct Current Dc Voltage
12 V
Specifications Face Nut
Black Metal
Specifications Handle Color
Clear
Specifications Handle Length
11/16 in | 17.5 mm
Specifications Handle Material
Plastic
Specifications Handle Type
Wedge
Specifications Hex Nut Material
Nickel-Plated
Specifications Mounting Stem Length
15/32 in | 11.9 mm
Specifications Mounting Stem Material
Black Nylon Plastic
Specifications Mounting Stem Thread Size
15/32-32 in
Specifications Number Of Terminals
4
Specifications Panel Thickness
0 to 1/8 in | 0 to 3.17 mm
Specifications Terminal Type
Screw
Specifications Type
Single Pole Single Throw (SPST)
