CVP SPST Toggle Switch
CVP SPST Toggle Switch
SKU:CVP-c2368d
Dependable CVP SPST Toggle Switch for efficient performance in consumer and institutional applications.
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
CVP SPST Toggle Switch
$12.99
Quantity: 1
Claim Your Seller Account
CVP SPST Toggle Switch
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CVP SPST Toggle Switch is a reliable solution for various applications with its single pole single throw design and silver contacts for efficient conductivity. Featuring a nickel-plated brass stem, phenolic housing, and plated steel cap, this toggle switch is durable and versatile. With screw terminals, 25A at 12V, 15A at 24V, and 10A at 36V DC ratings, it offers dependable performance. The switch is easy to mount on panels up to 9/32" thickness. Ideal for consumer and institutional use, meeting rigorous quality standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Accessories Accessories
Item # - 81264Item Name - Accessories for Toggle SwitchesDescription - Countersunk faceplate switch guards. Surface mount switch guard. Lockout switch guard cover. Emergency marine cutoff lanyards.Housing - Silicone RubberItem # - 81264-01Item Name - Accessories for Toggle SwitchesDescription - Countersunk faceplate switch guards. Surface mount switch guard. Lockout switch guard cover. Emergency marine cutoff lanyards.Housing - Silicone Rubber
Specifications Cap Material
Plated Steel
Specifications Contact Material
Silver
Specifications Current At 12 Volt V Voltage
25 A
Specifications Current At 24 Volt V Voltage
15 A
Specifications Current At 36 Volt V Voltage
10 A
Specifications Direct Current Dc Voltage
12 V | 24 V | 36 V
Specifications Handle Length
11/16 in | 17.5 mm
Specifications Handle Material
Nickel Plated Brass
Specifications Handle Type
Standard
Specifications Housing
Phenolic
Specifications Mounting Hardware
Nickel-Plated Brass
Specifications Mounting Stem Length
15/32 in | 11.9 mm
Specifications Mounting Stem Material
Nickel-Plated Brass
Specifications Mounting Stem Thread Size
15/32-32 in
Specifications Number Of Terminals
2
Specifications Panel Thickness
9/32 in | 7.1 mm
Specifications Terminal Type
Screw
Specifications Type
Single Pole Single Throw (SPST)
