CX04PM Manifold Coaxial Valve
CX04PM Manifold Coaxial Valve
SKU:ACC-79957f
High-performance 2/2 Way Plug-In Coaxial Valve with brass body, 64 bar max pressure, 24V, IP65 protection.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
CX04PM Manifold Coaxial Valve
$149.99
Quantity: 1
Claim Your Seller Account
CX04PM Manifold Coaxial Valve
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The CX04PM Manifold Coaxial Valve is a high-performance 2/2 Way Plug-In valve designed for reliable and efficient operation. Constructed with brass body material and Fluorocarbon/PTFE seal material, this valve offers a maximum pressure of 64 bar and operates between -10 to 100 ºC. With a 24V voltage requirement and Electric actuator type, it ensures precise control and superior performance. Meeting IP 65 protection standards, this valve is suitable for a wide range of applications, delivering optimal functionality and durability.
Product Specifications
Dimensions Height
7.60 in | 193 mm
Dimensions Length
2.05 in | 52 mm
Specifications 3 Day Lead Time
No
Specifications Actuator Type
Electric
Specifications Body Material
Brass
Specifications Degree Of Protection
IP 65 When Fitted with Connector Plug
Specifications Division
ACCESSORIES
Specifications Number Of Ways
2/2
Specifications Operating Pressure Max
64 bar | 928 psi
Specifications Operating Temperature Max
100 ºC | 212 ºF
Specifications Operating Temperature Min
-10 ºC | 14 ºF
Specifications Pressure Max
64 bar | 928 psi
Specifications Product
BALL VALVES
Specifications Product Group Family
PROCESS AND AUTOMATED VALVES
Specifications Seal Material
Static Seal: Fluorocarbon (FKM)Dynamic Seal: Polytetrafluoroethylene (PTFE)
Specifications Series
CX Plug-In
Specifications Switching Function
Normally Closed
Specifications Thread Size
G 3/8
Specifications Thread Type
BSPP
Specifications Type
2/2 Way Manifold Coaxial Valve Plug-In
Specifications Voltage
24 V
Specifications Weight
2.053 kg | 4.53 lb
